Overview
The Schneider Electric Elau SM-070-60-020-P1-45-M1-B0 is a compact servo motor from the PacDrive motion control family, engineered for precision positioning and synchronized drive applications. This used unit combines reliable stepper/servo hybrid characteristics with integrated electrical braking and multi-turn encoder feedback, making it suitable for textile machinery, packaging equipment, and general industrial automation requiring coordinated axis control.
Key Features
- 70 mm flange mounting footprint—compact and retrofit-compatible
- 24 VDC supply voltage—standard industrial control loop power
- Integrated electromagnetic brake (M1 designation) with smooth shaft output
- SINCOS multi-turn absolute encoder (B0) for position feedback without homing
- 6000 RPM maximum speed with smooth low-speed torque delivery
- Proven PacDrive ecosystem integration for motion control systems
Technical Specifications
- Manufacturer: Schneider Electric / Elau AG
- Model Number: SM-070/60/020/P1/45/M1/B0
- Part Number: 19202604-511
- Motor Type: Servo motor with integrated brake
- Supply Voltage: 24 VDC
- Rated Power: 70 W continuous (60 W thermal)
- Output Torque: 0.20 Nm (2.0 kgcm)
- Maximum Speed: 6000 RPM
- Flange Size: 70 mm IEC standard
- Shaft Type: Smooth (keyless) output shaft
- Feedback System: SINCOS multi-turn absolute encoder (B0)
- Brake: Integrated electromagnetic holding brake
- Mounting: Flange mounted, face-mount connector
- Condition: Used, fully functional and tested
Typical Applications
- Textile machinery—warp and weft control, patterning systems
- Packaging and labeling—carton forming, case erecting, label application
- Printing and converting—register control, web drive
- Assembly automation—synchronized multi-axis indexing
- Material handling—metered hopper and chute control
- Replacement for aging PacDrive servo installations requiring drop-in compatibility
Compatibility & Replacements
Compatible With
- Schneider Electric PacDrive servo controllers and motion control modules
- Elau CNC and industrial automation platforms
- CANopen and analog command interfaces (36 VDC relay logic)
- Standard industrial 24 VDC control power supplies
- IEC 60939 flange-mount servo couplings and gearboxes
Replaces / Drop-In Replacement For
- SM-070/60/020/P0/45/M1/B0 (P0 variant with different encoder)
- SM-070/60/020/P1/45/S1/B0 (S1 variant without integrated brake)
- Other Elau SM-070 series units requiring 24VDC, 70mm flange mount
Works With
- PacDrive multi-axis servo system architecture
- Elau automation software and commissioning tools
- SINCOS encoder decoder modules and CANopen gateways
- Third-party motion control systems supporting absolute encoder feedback
