Overview
The Eaton Cutler Hammer 10250T102 is a compact, industrial-grade pushbutton operator designed for harsh environments and demanding automation control applications. Eaton’s 10250T line of 30.5mm pushbuttons features a heavy-duty zinc die cast construction. The 10250T102 is a red momentary Pushbutton Operator features zinc die-cast construction with chrome plated housing and mounting nuts. This non-illuminated pushbutton delivers reliable performance across NEMA 3, 3R, 4, 4X, 12, and 13 enclosure ratings.
Key Features
- Reliability nibs improve contact reliability even under dry circuit and fine dust conditions.
- Enclosed silver contacts with reliability nibs improves contact reliability even under dry circuits and fine dust conditions.
- Drainage holes prevent buildup of liquids inside the operator which can prevent operation in freezing environment.
- Grounding nibs bit through paint and other coating to secure grounding.
- Flush mounting design for seamless panel integration
- Momentary (spring-return) operation for safety-critical applications
Technical Specifications
The 10250T102 meets demanding industrial standards and offers robust performance:
- Button Size: 30.5 mm diameter
- Button Color: Red plastic actuator
- Actuation Type: Momentary (spring-return)
- Mounting Style: Flush
- Contact Type: Silver with reliability nibs
- Rated Current (AC-15): 6A @ 120Vac, 4A @ 240Vac, 2A @ 660Vac
- Rated Current (DC-13): 1A @ 125Vdc, 0.55A @ 250Vdc, 0.1A @ 660Vdc
- IP Rating: IP65
- NEMA Ratings: NEMA 3, 3R, 4, 4X, 12, 13
- Material: Die-cast zinc body with chrome-plated housing
- Dimensions: 1.9 in (L) × 1.9 in (W) × 2 in (H)
- Illumination: Non-illuminated
- Series: 10250T
Typical Applications
The Eaton 10250T102 is widely deployed in:
- Emergency stop and control circuits in manufacturing equipment
- Industrial automation and logic control equipment
- Pump and motor control stations
- Watertight/oiltight panel-mounted control systems
- Class I Division 2 hazardous locations
- Food processing and chemical facility control panels
Compatibility & Replacements
The 10250T102 is part of Eaton’s 10250T series of heavy-duty industrial pushbuttons. It is functionally compatible with other 30.5mm momentary red pushbutton operators from the 10250T family. When specifying replacement operators, confirm the same mounting style (flush), actuation type (momentary), NEMA rating requirements, and contact configuration. Eaton provides variant options including different colors, illuminated versions, maintained (latching) actuation, and auxiliary contact configurations within the 10250T series.
