Overview
The Sprecher + Schuh D7-1MP pushbutton enclosure is a compact, durable metal control enclosure engineered for industrial automation and switching applications. Built to NEMA 4/13 specifications, this aluminum-housed unit provides reliable operator interface and signal control in manufacturing, process control, and electrical panel applications. The D7 series represents Sprecher + Schuh’s economical approach to high-performance pilot device solutions.
Key Features
- NEMA 4/13 rated metal enclosure for washdown and oil-resistant applications
- IP 66 rated front elements for submersion, oil, and dirt protection
- Aluminum construction with corrosion-resistant chrome plating finish
- Single outlet configuration for streamlined panel mounting
- Modular design allows interchangeability with other D7 series components
- Anti-rotation tab prevents accidental rotation or dislodging from panel cutout
Technical Specifications
- Manufacturer: Sprecher + Schuh
- Model: D7-1MP
- Series: D7
- Enclosure Material: Aluminum with chrome plating
- Rating: NEMA 4/13, IP 66
- Mounting Hole Size: 22.5mm
- Number of Outlets: 1
- Dimensions (L × W × D): 3-9/32 in × 3-11/32 in × 3-5/32 in (84.4 mm × 85.7 mm × 79.4 mm)
- Finish: Gray with corrosion-resistant coating
- Installation: Panel-mount with central mounting ring and anti-rotation tab
Typical Applications
- Industrial control panels and electrical enclosures
- Manufacturing equipment and production line controls
- Washdown environments requiring NEMA 4/13 protection
- Motor control and starter circuits
- Process control signaling and switching stations
- Food processing, chemical, and petrochemical industry applications
Compatibility & Replacements
Compatible With
- D7 series pushbutton operators (illuminated and non-illuminated)
- D7 series contact blocks and power modules
- D7 series legend plates and inscription rings
- Standard 22.5mm pilot device configurations
- Industrial control panel applications using 22mm pushbutton standards
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. The D7-1MP is a single-outlet enclosure; ensure your replacement application matches this outlet configuration.
Works With
- D7 monolithic pilot devices (D7D series)
- D7 modular pushbutton assemblies
- Standard motor control contactors and starters
- Low-voltage industrial control systems
- UL-approved control circuit applications
