Overview
The Hoffman A-301606LP is a NEMA Type 12 wall-mounted electrical enclosure designed for housing controls, instruments, and pneumatic components in demanding industrial applications. Built by nVent Hoffman, a leading manufacturer of industrial electrical enclosures, this model combines robust steel construction with reliable protection against dust, dirt, oil spray, and water—making it ideal for manufacturing floors, utility rooms, and control panel installations where environmental exposure is a concern.
Key Features
- NEMA Type 12 and Type 13 rated for superior dust and water protection (IP65 equivalent)
- Continuous piano hinge design with screw-down clamps for secure, reliable closure
- White interior finish increases visibility for components; ANSI 61 gray exterior
- Welded and ground-smooth seams for structural integrity and durability
- Padlocking hasp and staple for security of sensitive electrical equipment
- Made in USA with UL 508A and CSA certification for industrial-grade reliability
Technical Specifications
- Model: A-301606LP / UPC 783510279103
- NEMA Rating: Type 12, Type 13 (IP65)
- Dimensions (H×W×D): 30″ × 16″ × 6″
- Material: 14–16 gauge mild steel
- Door Gauge: 14 gauge steel
- Finish: White interior, ANSI 61 gray exterior powder coat
- Hinge Type: Continuous (piano hinge) with clamps
- Certifications: UL 508A Listed (Type 12, 13); cUL Listed per CSA C22.2 No. 94; CSA File No. 42186
- Mounting: Wall-mount with external brackets
Typical Applications
- Industrial manufacturing control rooms and equipment enclosures
- Water treatment and wastewater facilities requiring dust and water protection
- Food processing plants where washdown environments demand sealed enclosure protection
- Utility and facility management electrical installations
- HVAC and mechanical system control panels
- Machinery guarding and emergency stop stations
Compatibility & Replacements
Compatible With
- Standard electrical components: pushbuttons, selector switches, indicator lights, terminal blocks
- Motor starters and overload relays
- Programmable Logic Controllers (PLCs) and automation devices
- Pneumatic control valves and regulators
- Power distribution equipment and circuit breakers
Replaces / Drop-In Replacement For
- Other Hoffman A-LP Series continuous hinge wall-mount enclosures in the same size class
- Verify compatibility with your specific application requirements before ordering
Works With
- Optional stainless steel, conductive, composite, and aluminum panel inserts (sold separately)
- Standard electrical mounting hardware and DIN rail accessories
- Thermal management solutions: Hoffman enclosure coolers and air conditioners (retrofit-compatible)
