Overview
The Hoffman A-12106CHSCFG is a NEMA Type 4X continuous hinge fiberglass enclosure designed for demanding industrial and commercial control applications. Measuring 12 x 10 x 6 inches with wall-mount configuration, this enclosure combines robust fiberglass construction with stainless steel hardware for long-term durability in corrosive environments including coastal, chemical processing, food production, and outdoor installations.
Key Features
- Compression-molded fiberglass-reinforced polyester construction offers excellent impact resistance, thermal insulation, and corrosion resistance
- Outstanding chemical and temperature-resistance qualities with excellent weatherability; easily punched, drilled, filed or sawed for custom modifications
- Removable hinged cover with Type 316 stainless steel hinge pin
- Two captivated Type 316 stainless steel slotted cover screws for secure fastening
- UL listed, File #E64358
- Gasket assures water-tight and dust-tight seal; polyester mounting brackets and stainless steel attachment screws provided
Technical Specifications
- Model: A-12106CHSCFG
- Exterior Dimensions (HxWxD): 12.00 × 10.00 × 6.00 inches
- Material: Compression-molded fiberglass-reinforced polyester
- NEMA Rating: Type 4, 4X, 12, 13
- Door Type: Continuous hinge screw-cover
- Finish: Light gray
- Mounting: Wall mount
- Hinge Material: Type 316 stainless steel
- Fasteners: Stainless steel hardware
- Certifications: UL listed
- Country of Origin: US
Typical Applications
- Industrial process control panel housings
- Outdoor electrical control stations in coastal or marine environments
- Chemical processing and food production facilities
- Water treatment and utility applications
- HVAC and facility management control systems
- Telecommunications and networking equipment protection
Compatibility & Replacements
Compatible With
- Standard industrial terminal blocks and DIN rail components
- Industry-standard control relays and contactors
- Modular electrical components requiring wall-mount protection
- Custom internal mounting panels and polycarbonate windows (optional)
Replaces / Drop-In Replacement For
- Other Hoffman Type 4X 12x10x6 enclosures with continuous hinge design
- Generic fiberglass NEMA 4X wall-mount junction boxes of equivalent size
- Verify specific model compatibility with your system integrator before ordering
Works With
- Standard industrial control wiring and terminal block assemblies
- Molded-in brass inserts for custom mounting plate installation
- Optional Hoffman accessory panels and internal hardware
- All standard enclosure-mount electrical components and devices
