Overview
The SMC NCDMB088-0756 is a compact double-acting pneumatic cylinder engineered for precision automation and industrial control applications. This cylinder combines a 7/8″ bore with a 7.56″ stroke and operates at a maximum rated pressure of 250 PSI (1.7 MPa), delivering consistent force output for linear motion in machinery, assembly lines, material handling, and process automation. As a standard single-rod configuration, it provides proven reliability across diverse industrial sectors.
Key Features
- Double-acting design for bi-directional motion control
- 7/8″ bore size (088) with 7.56″ effective stroke
- 250 PSI (1.7 MPa) maximum operating pressure
- Compact, space-efficient construction ideal for OEM integration
- Available with optional auto-switch mounting and rod boot configurations
- Single-rod design for asymmetrical load applications
Technical Specifications
- Bore Size: 7/8″ (0.875″)
- Stroke Length: 7.56″
- Max Operating Pressure: 250 PSI (1.7 MPa)
- Cylinder Type: Double-acting, single-rod
- Rod Configuration: Non-rotating
- Piston Rod Material: Hardened steel
- Body Material: Aluminum or ductile iron (standard)
- Cushioning: Available with or without cushioning options
- Mounting Options: Nose mount, rear mount, end mount, rod mount available
- Operating Temperature Range: Standard pneumatic (5–60°C typical)
Typical Applications
The SMC NCDMB088-0756 is suited for a broad range of industrial automation tasks, including:
- Automated assembly and manufacturing equipment
- Material handling and transfer systems
- Press brake and stamping machine automation
- Packaging and labeling machinery
- Clamping and workholding fixtures
- Machine tool feed drives and positioning systems
- Process automation and control systems
Compatibility & Replacements
Compatible With
- Standard ISO pneumatic porting (SAE, NPT, ISO 6149)
- Manifold blocks and sandwich configurations
- Most SMC solenoid valves and directional control valves
- Industry-standard pneumatic tubing and fittings
- PLC and industrial automation control systems
- 3/2 and 4/2 directional control valve circuits
Replaces / Drop-In Replacement For
The NCDMB088-0756 is the factory part number. Verify compatibility with your system integrator before ordering alternate equivalent models from other manufacturers, as port sizing and mounting may vary.
Works With
- SMC CX series solenoid valves
- SMC LS series logic gates
- SMC manual directional control valves
- Pneumatic timing modules and flow control units
- Industrial PLC/automation control platforms (Allen-Bradley, Siemens, etc.)
- ISO ported manifold systems
- Standard 24 VDC pilot solenoid circuits
