Overview
The SMC MGQM25-30 is a compact guided pneumatic cylinder from the MGQ series designed for applications requiring high lateral load resistance and non-rotating accuracy. Air cylinder with an integrated guide achieves lateral load resistance and high non-rotating accuracy; suitable for stopper and lifter in the conveyor line. This double-acting unit features a 25mm bore and 30mm stroke, making it an efficient solution for linear actuation in industrial automation.
Key Features
- Compact guided pneumatic cylinder with a bore of 25mm and a stroke of 30mm
- Double acting cylinder action with 0.1 to 1 mpa pressure range and -10 to 60°C operating temperature
- Rubber cushion for smooth load deceleration
- Integrated guide shafts isolate load bearing from actuator rod movement
- Two basic models include a self-lubricating slide bushing and a linear ball bearing style
- Ideal for material handling, conveyor systems, and heavy-load applications
Technical Specifications
Typical Applications
Ideal for material handling applications. The SMC MGQM25-30 is commonly used as stopper and lifter mechanisms in conveyor lines, workstation fixturing, and automated positioning systems where controlled linear motion with lateral load capacity is required. The guided design prevents rod binding and enables smooth operation under off-center loading conditions.
Compatibility & Replacements
Compatible With
- Standard pneumatic 4/2 and 4/3 directional control valves
- 0.1–1.0 MPa (1–10 bar) pressure systems
- Factory automation and conveyor systems
- Manual and solenoid-actuated control circuits
Replaces / Drop-In Replacement For
The base MGQM25-30 model directly interchanges with port-compatible variants including MGQM25-30-Y7PW, MGQM25-30-M9BZ, MGQM25-30-Y59AL, and MGQM25-30-Y7PVSAPC. Verify exact porting and accessory requirements with your system integrator before ordering, as extended models may include solenoid switches or alternative port configurations.
Works With
- Pneumatic directional control valves (ISO 4401 NG10/CETOP-05 and compact models)
- Pneumatic distribution systems and FRL (filter, regulator, lubricator) units
- Mechanical limit switches and proximity sensors for position detection
- Industrial PLC and automation controllers via solenoid valve circuits
