Overview
The SMC CP96SDB63-320C is a high-performance ISO 15552 profile pneumatic cylinder engineered for reliable actuation in industrial automation. This double-acting cylinder features pneumatic damping at both ends and elastic damping, enabling smooth operation and reduced noise at end-of-stroke conditions. The CP96 series combines durability with precision control, making it suitable for assembly machinery, transfer systems, clamping applications, and process automation.
Key Features
- Bore diameter Ø63 mm with 320 mm stroke
- ISO 15552 profile body cylinder design
- Double-acting with both air and bumper cushioning to reduce cushion stroke length, cycle time, and noise
- Built-in magnet (D) for sensor feedback compatibility
- Single rod, basic (B) mounting configuration
- Pre-wired connector option available (0.5m)
Technical Specifications
The SMC CP96SDB63-320C meets ISO 15552 standards for profile cylinders and is available in multiple bore sizes and stroke lengths within the CP96 series.
Typical Applications
- Transfer and positioning systems
- Clamping and holding fixtures
- Assembly line automation
- Material handling equipment
- Press and straightening applications
- Industrial machinery requiring controlled end-of-stroke deceleration
