Overview
The SMC CDG1BA40-110 is a double-acting, single rod air cylinder from SMC’s CG1 series, engineered for reliable performance in industrial pneumatic systems. The CG1 series offers single rod, double acting air cylinder design with 8 bore sizes, with this unit featuring a 40mm bore diameter. Built with impact extruded aluminum tube construction to produce an extraordinarily smooth internal finish, allowing low break-away pressure and smooth stroke action, the CDG1BA40-110 delivers consistent performance across a wide range of automation tasks.
Key Features
- 40mm bore, double-acting single rod design for efficient power delivery
- Impact extruded aluminum tube for smooth internal finish and minimal break-away pressure
- Female piston rod threads available as standard option for flexible mounting configurations
- Auto switch capable for position detection and control integration
- Various mounting bracket options available for diverse system integration
- Compact round body design suitable for space-constrained installations
Technical Specifications
The CDG1BA40-110 meets industrial pneumatic standards and is designed for reliable operation in automated assembly lines, material handling systems, and production equipment. Specifications include 40mm bore diameter, 110mm stroke length, double-acting operation, and standard female rod-end threading. Operating pressure range is typical for SMC pneumatic cylinders. The unit features a built-in magnet for auto switch integration, aluminum construction for lightweight performance, and smooth bore technology for extended service life.
Typical Applications
- Industrial assembly and packaging machinery
- Automated material handling and positioning systems
- Manufacturing production line actuators
- Precision press and clamping applications
- Lifting and lowering mechanisms in automated systems
Compatibility & Replacements
Compatible With
- Standard pneumatic control systems (0–10 bar operating range)
- SMC solenoid valve manifolds and directional control valves
- Auto switch sensors and position detection systems
- Industrial PLC and automation controller networks
- Common 40mm bore pneumatic system configurations
Replaces / Drop-In Replacement For
The CDG1BA40-110 shares the same bore (40mm) and rod-end configuration with other SMC CG1 series cylinders of equivalent stroke. Verify exact model compatibility with your system integrator before ordering to ensure proper fit and performance.
Works With
- SMC air preparation units and pneumatic regulators
- Proportional and directional solenoid valves
- Pneumatic logic circuits and cascade control systems
- Pressure switches and flow control devices
- Industry-standard auto switch and proximity sensor interfaces
