Overview
The Schrader Bellows 02.50 NSC 9 0.500 low-profile pneumatic cylinder is designed for space-constrained industrial applications requiring compact linear motion. This NSC series unit features a 2.5-inch bore with a 0.5-inch stroke, providing controlled actuation in machinery, automation equipment, and mechanical control systems. The 250 PSI maximum operating pressure rating ensures reliable performance across standard pneumatic system pressures.
Key Features
- Low-profile compact design fits tight mounting spaces
- 2.5-inch bore diameter with 0.5-inch stroke length for precision positioning
- 250 PSI maximum operating pressure rating
- Standard ports for pneumatic system integration
- Durable construction suitable for industrial machinery and automation
- Direct replacement for existing Schrader Bellows NSC series applications
Technical Specifications
See specifications table below for complete details on bore size, stroke, pressure rating, ports, and mounting information.
Typical Applications
- Compact machinery clamping and pressing operations
- Automated assembly line positioning and control
- Industrial tooling and fixturing actuation
- Packaging equipment linear motion
- Material handling and transfer systems
- Factory automation control and sequencing
Compatibility & Replacements
Compatible With
- Standard pneumatic systems operating 40–250 PSI
- Industrial air compressors and pneumatic networks
- Standard NPT and SAE port connections
- Parker pneumatic control valves and manifolds
- Factory automation control systems requiring linear actuation
Replaces / Drop-In Replacement For
- Other Schrader Bellows 02.50 NSC 9 models with identical bore and stroke
- Equivalent low-profile cylinders in the NSC series lineup
- Verify compatibility with your system integrator before ordering to confirm mounting and port specifications.
Works With
- Parker pneumatic control systems and solenoid valves
- Standard ISO 4401 (CETOP) manifold mounting
- Pneumatic tubing and fittings (1/4″ NPT standard)
- Industrial PLC and automation controllers for valve sequencing
- Pressure regulators, lubricators, and filters
