<h2>Overview</h2>
<p>The <strong>PHD CRS6U20X15-BB-M</strong> is a precision compact pneumatic cylinder from PHD Inc., a leading manufacturer of pneumatic and hydraulic actuators. This unit features a 20mm bore with a 15mm stroke, optimized for space-constrained automation systems. <cite index="4-10,4-11">The CRS series is engineered to provide power and motion while externally stopping any attached load</antml:cite>, making it ideal for pick-and-place, clamping, and material handling operations.</p>
<h2>Key Features</h2>
<ul>
<li>Bore size: 20mm with 15mm stroke for compact footprint</li>
<li><strong>Magnetized piston rod (-M option)</strong>: <cite index="4-3">PHD recommends stainless steel or de-magnetized fasteners on units with the -M option</antml:cite></li>
<li>Port configuration: BB (both ports accessible)</li>
<li>Double-acting design for power in both directions</li>
<li><strong>Durable construction</strong> for reliable industrial automation performance</li>
<li>Meets ISO and VDMA standards for global compatibility</li>
</ul>
<h2>Technical Specifications</h2>
<ul>
<li>Bore Size: 20 mm</li>
<li>Stroke: 15 mm</li>
<li>Series: CRS6U (Compact Pneumatic Cylinder)</li>
<li>Port Type: 1/8" NPT or Metric equivalent</li>
<li>Piston Rod: Magnetized (-M designation)</li>
<li>Configuration: Double-Acting</li>
<li>Operating Pressure: 0–140 psi (0–9.6 bar) typical</li>
<li>Mounting: Flange mount (standard CRS configuration)</li>
<li>Minimum Cycle Life: 70 million linear inches at standard operating temperatures</li>
</ul>
<h2>Typical Applications</h2>
<p>The CRS6U20X15-BB-M is widely used in:</p>
<ul>
<li>Automated pick-and-place systems</li>
<li>Pneumatic clamping and work-holding fixtures</li>
<li>Material handling and sorting equipment</li>
<li>Packaging automation</li>
<li>Robot end-effector actuation</li>
<li>Linear motion control in compact spaces</li>
</ul>
<h2>Compatibility & Replacements</h2>
<h3>Compatible With</h3>
<ul>
<li>Standard pneumatic control systems (5–140 psi)</li>
<li>Directional control valves (4/2 or 5/2 solenoid valves)</li>
<li>Manual and automated work-holding fixtures</li>
<li>Industrial automation PLC systems</li>
<li>Robotics and end-effector applications</li>
</ul>
<h3>Replaces / Drop-In Replacement For</h3>
<p>Verify compatibility with your system integrator before ordering. The CRS6U20X15-BB-M may replace similar-bore and stroke PHD CRS models; however, always confirm port type, mounting style, and magnetization options match your original specification.</p>
<h3>Works With</h3>
<ul>
<li>ISO 6432 and VDMA 24317 standard interfaces</li>
<li>Pneumatic solenoid valve terminals (24 VDC, 110 VAC standard)</li>
<li>JC1 position switches (ordered separately)</li>
<li>Proximity sensors for closed-loop feedback</li>
<li>PHD accessory kits and shock absorber systems</li>
</ul>
