Overview
The Panasonic 100uF 35V radial aluminum electrolytic capacitor is a standard through-hole component designed for general-purpose filtering, smoothing, and energy storage in power supplies, audio amplifiers, industrial control circuits, and consumer electronics. These are bulk-packed (200 pieces per bag) to support high-volume repair, manufacturing, and prototyping needs. Temperature rating: +85°C maximum. Manufactured to consistent quality standards with proven reliability across decades of field deployment.
Key Features
- Capacitance: 100 microfarads (100µF)
- Voltage rating: 35V DC
- Temperature rating: –40°C to +85°C operating range
- Radial lead configuration for standard PCB or breadboard mounting
- Long endurance: 2000 hours at maximum rated temperature
- Bulk quantity (200 units per bag) reduces per-unit cost for production and maintenance stock
Technical Specifications
- Capacitance: 100 µF
- Voltage Rating: 35 V DC
- Tolerance: ±20% (typical)
- Temperature Range: –40°C to +85°C
- Endurance: 2000 hours @ 85°C
- Mounting Type: Radial lead (through-hole)
- Lead Spacing: Standard pitch (commonly 2.5 mm or 3.5 mm; verify with your board design)
- Equivalent Series Resistance (ESR): Low-to-moderate, typical for general-purpose aluminum electrolytics
- Packaging: Bag of 200 units
- RoHS Compliant: Yes (standard for Panasonic electronic components)
Typical Applications
Panasonic 100µF 35V aluminum electrolytic capacitors are widely used in:
- Power supply filtering and ripple reduction (AC-to-DC adapters, linear regulators)
- Audio amplifier coupling and decoupling circuits
- Microcontroller and microprocessor power decoupling
- Motor control circuits and relay drivers
- Industrial and commercial electronics repair and maintenance stock
- Educational prototyping and electronics hobbyist projects
Compatibility & Replacements
Compatible With
- All standard PCB designs requiring 35V nominal voltage headroom
- Through-hole breadboards and solderless prototyping boards
- Industrial power supplies, VFDs, and control modules
- Audio amplifiers and mixing consoles
- Consumer electronics (TVs, monitors, audio equipment)
- Legacy and modern circuit boards designed for radial aluminum electrolytics
Replaces / Drop-In Replacement For
Panasonic 100µF 35V capacitors in the AM series (such as ECA1VAM101X) are direct replacements for worn or failed capacitors with identical specifications. Always verify capacitance, voltage, and lead spacing before replacement.
Works With
- Hand-soldering and wave-soldering equipment
- Automated assembly machinery for through-hole placement
- Any schematic or PCB layout tool that accepts standard radial electrolytic footprints
- Industry-standard component testing and quality-assurance tools
