Overview
The Panasonic ECQ-UH Series metallized film capacitor is engineered for dependable operation across a wide range of industrial electrical applications. With a 125V rating and convenient bulk pack of 100 units, these capacitors deliver stable performance in filtering, energy storage, and signal coupling applications. Radial lead configuration simplifies board-level integration and retrofit installations.
Key Features
- 125V Rated Voltage: DC operating voltage suitable for general-purpose industrial circuits
- Metallized Polyester/Polypropylene Film: Stable dielectric material with self-healing properties in metallized construction
- Radial Lead Design: Standard axial or radial termination for versatile PCB mounting and manual wiring
- Bulk Packaging: 100-unit pack reduces component procurement overhead
- Panasonic Reliability: Manufactured by a globally recognized industrial components supplier
Technical Specifications
Complete technical specifications including exact capacitance values (µF), tolerance ratings, operating temperature range, and dimensional data should be verified with Panasonic’s current datasheet or technical documentation. Contact our engineering team for detailed spec sheets for your specific application.
Typical Applications
- Power supply filtering and smoothing
- Signal coupling and decoupling circuits
- Interference suppression in industrial equipment
- Energy storage in low-voltage DC systems
- Audio and instrumentation circuits
- Control circuit applications
Compatibility & Replacements
Compatible With
- Industrial power supplies (≤125V DC rated)
- Frequency converters and motor drives
- Control systems requiring DC filtering
- General-purpose electronic assemblies at 125V and below
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. Similar Panasonic metallized film capacitor series include ECQ-E, ECQ-UB, and ECQ-UA models; however, direct replacement capability depends on exact capacitance, tolerance, and lead configuration of your original component.
Works With
- Standard PCB assembly equipment (wave solder, reflow)
- Manual wiring and termination in retrofit applications
- Any circuit topology operating at or below rated voltage
