Overview
The Norgren VM1006001US is a modular pneumatic valve island from the VM10 series, engineered for flexible and reliable control of compressed air systems in industrial automation. This 6-station configuration features 25-pin D-sub multipole electrical connectivity, enabling straightforward integration with control systems. The VM10 valve islands when fully assembled have an IP65 protection rating, providing robust environmental sealing for dusty or damp production environments. The unit supports ATEX certification for use in hazardous zones where explosive atmospheres may be present.
Key Features
- 6-station pneumatic valve manifold with interchangeable valve slices
- 25-pin D-sub multipole electrical connector for simplified wiring
- IP65 protection rating for sealed operation in harsh environments
- ATEX-certified for hazardous area deployment
- Support for 3/2, 5/2, and 5/3 valve configurations via slices
- Integrates with fieldbus protocols including DeviceNet, CANopen, and PROFIBUS
- Compact, lightweight design with pneumatic quick-disconnect base (Pneumapole)
Technical Specifications
- Part Number: VM1006001US
- Series: VM10
- Station Configuration: 6-station manifold
- Electrical Interface: 25-pin D-sub multipole
- Protection Rating: IP65
- Certification: ATEX
- Valve Types Supported: 2×3/2, 5/2, 5/3 spool valves
- Operating Medium: Compressed air (filtered, lubricated and non-lubricated)
- Maximum Operating Pressure: 8 bar (116 psi)
- Port Sizes Available: 3 mm, 4 mm, 6 mm integral push-in fittings
- Weight: Approximately 4.0 lbs (1.8 kg)
- Communication Protocols: DeviceNet, CANopen, PROFIBUS-DP/PA, Interbus-S
Typical Applications
The Norgren VM1006001US excels in industrial environments requiring centralized pneumatic valve control:
- Factory automation and assembly line control systems
- Hazardous zone operations (Zone 1/2 ATEX environments)
- Machine tool clamping and workholding circuits
- Packaging machinery with networked valve control
- Process automation requiring multi-station pneumatic distribution
- Integration with programmable logic controllers (PLCs) via fieldbus networks
Compatibility & Replacements
Compatible With
- Allen-Bradley CompactLogix and ControlLogix PLCs (via DeviceNet modules)
- Siemens S7-300 and S7-1200 controllers (via PROFIBUS-DP or CANopen gateways)
- Mitsubishi FX and Q-series PLCs (via CANopen/fieldbus adapters)
- Omron PLCs with DeviceNet or CANopen support
- Industrial PCs and distributed control systems with fieldbus master cards
- Norgren configurator software for valve island programming
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. The VM1006001US replaces earlier versions of 6-station VM10 multipole manifolds with equivalent electrical and pneumatic port configurations.
Works With
- DeviceNet communication (CAN-based industrial fieldbus)
- PROFIBUS-DP/PA (legacy and current automation networks)
- CANopen protocols (machine-to-machine communication)
- Interbus-S fieldbus systems
- Norgren valve island configurator software for custom station programming
- RSNetWorx for DeviceNet node commissioning and parameter setting
