Overview
The Murata Erie DV11PS35D is a compact variable trimmer capacitor designed for precision frequency tuning and RF circuit adjustment. Supplied as a box of 100 units, this 538 series component offers ceramic construction and a capacitance range of 9pF to 35pF, making it suitable for both laboratory work and production assembly. Each unit is individually packaged for easy identification and distribution across multiple assembly stations.
Key Features
- Capacitance range: 9pF to 35pF (variable trimmer design)
- Ceramic dielectric construction for stable performance
- 200V rated voltage for standard RF and tuning applications
- Temperature coefficient: N650 ppm/°C for predictable drift characteristics
- Compact form factor (0.375″ diameter × 0.275″ length)
- Bulk supply: 100 units per box, ideal for production runs or stocking
Technical Specifications
- Capacitance (Max): 35 pF
- Capacitance Range: 9 pF – 35 pF
- Voltage Rating: 200 V DC
- Temperature Range: −55°C to +125°C
- Temperature Coefficient: N650 ppm/°C
- Dielectric Material: Ceramic
- Case Size: 0.375″ Dia × 0.275″ Length
- Series: DV11 (538 series trimmer)
- Packaging: Box of 100 units
Typical Applications
Variable trimmer capacitors such as the DV11PS35D are commonly used in:
- RF and microwave circuit tuning and impedance matching
- Frequency calibration and fine-tuning in oscillators and filters
- Test and measurement equipment requiring adjustable capacitance
- Communication system alignment and compensation
- Component assortment kits for electronics labs and educational institutions
- Production assembly where bulk quantities of trim caps are required
Compatibility & Replacements
Compatible With
- Standard PCB footprints for 0.375″ diameter radial lead components
- RF circuit modules requiring 200V maximum operating voltage
- Low-frequency and VHF/UHF tuning networks
- Analog instrumentation and test equipment
Replaces / Drop-In Replacement For
The DV11PS35D is part of the Murata DV11 trimmer family and shares dimensional and electrical compatibility with other 538 series variable capacitors in the same capacitance range. Verify compatibility with your original circuit design or equipment OEM datasheet before substitution.
Works With
- Analog RF circuit design and breadboarding
- PCB assembly workflows and tuning processes
- Laboratory measurement and calibration setups
- Standard soldering and component mounting techniques
