Overview
The ITE AT1210A-D10 is a compact 12VDC power supply enclosure built for reliable power distribution in CCTV, surveillance, and security camera applications. This unit converts standard AC input (110–220VAC, 60Hz) to regulated 12VDC output distributed across 18 fused ports. Each output port is protected by individual 3.0A fuses, ensuring equipment safety and preventing cascading failures across your system.
Key Features
- 18 Fused Output Ports — Individual 3.0A fuses protect each channel independently
- 10A Total Supply Current — Robust 12VDC power delivery for up to 18 connected devices
- UL Listed Safety — Meets UL/CUL standards for reliable performance and compliance
- Compact Enclosure Design — Space-efficient aluminum construction for installation in tight spaces
- Status Indicators — AC power switch and power LED indicator for at-a-glance monitoring
- Included Power Cord — Ready to install out of the box
Technical Specifications
- Output Voltage: 12VDC
- Supply Current: 10A @ 12VDC
- Number of Ports: 18 fused outputs
- Port Fusing: 3.0A per port
- Input Voltage: 110–220VAC, 60Hz
- Body Material: Aluminum
- Dimensions: 10.6″H × 8.0″W × 3.9″D
- Weight: 2 kg (4.4 lbs)
- Certifications: UL Listed / CUL Listed
- Mounting: Wall or enclosure mount
- Accessories Included: Power cord
Typical Applications
The AT1210A-D10 is commonly deployed in:
- Multi-camera CCTV surveillance systems
- Security monitoring installations with 12V camera arrays
- Access control and alarm system power distribution
- Centralized power hubs for industrial security networks
- Building automation and facility monitoring systems
- Backup and redundant power distribution for critical camera feeds
Compatibility & Replacements
Compatible With
- 12VDC CCTV cameras and recorders
- Security camera systems using 12V power distribution
- Access control systems with 12V solenoids and readers
- LED lighting systems rated for 12VDC
- Alarm panels and sensors (12V compatible)
- Standard industrial 110–220VAC power sources
Replaces / Drop-In Replacement For
The AT1210A-D10 directly replaces earlier versions and similar 18-port, 10A fused power distribution enclosures in legacy CCTV installations. Verify compatibility with your specific system integrator before ordering to ensure voltage and connector specifications match your existing configuration.
Works With
- LTS (Light, Time, System) camera and DVR product lines
- Standard 12VDC barrel connectors and terminal block outputs
- Wall mounting hardware and DIN rail adapters
- Fuse-replacement accessories (3.0A fuses, standard 5×20mm)
