Overview
The Industrial Devices N2D-10-5B-8-MS2-MT1-BS24 is a compact electric cylinder from the proven N2D series, engineered for reliable linear actuation in industrial automation, assembly, and positioning applications. This unit combines stepper or servo motor control with a precision leadscrew mechanism and 24V electromagnetic brake, making it suitable for applications requiring repeatable, controlled motion with load holding capability.
Key Features
- 1.0-inch bore with 5-inch stroke for compact machine integration
- 24V electric brake on leadscrew (-BS24) for load holding without external support
- MS2 motor mount configuration for standard servo/stepper motor coupling
- MT1 rod end type for flexible mounting and connection options
- Precision leadscrew drive (8-inch pitch) for smooth, controlled extension and retraction
- Industrial-duty construction suitable for factory automation, material handling, and positioning systems
Technical Specifications
- Bore Diameter: 1.0 inch (10mm nominal)
- Stroke Length: 5.0 inches
- Leadscrew Pitch: 8 threads per inch
- Brake Voltage: 24 VDC
- Motor Mount: MS2 (standard servo/stepper interface)
- Rod End Type: MT1 (threaded or clevis)
- Brake Type: Electromagnetic brake on leadscrew, holds load under power loss
- Operating Environment: Standard industrial (consult manual for temperature/duty cycle limits)
- Series: Industrial Devices N2D
- Warranty: Industrial Devices one-year manufacturer warranty against defects
Typical Applications
- CNC machine tool positioning and clamping
- Assembly line actuators for part feeding and positioning
- Industrial automation and robotic system linear motion
- Precision manufacturing work-holding and alignment
- Medical device and laboratory equipment actuation
- Testing and measurement equipment positioning
Compatibility & Replacements
Compatible With
- NEMA 23, NEMA 34 stepper motors (via MS2 coupling)
- Servo motors with equivalent mount footprint
- 24V DC power supplies for brake actuation
- Standard industrial motor controllers and motion control systems
- PLCs and motion control cards via pulse/direction or step/direction interfaces
Replaces / Drop-In Replacement For
- Other Industrial Devices N2D-10-5B-8 configurations without brake
- Verify exact compatibility with your system integrator before ordering, as rod end type (MT1) and motor mount (MS2) must match your application
Works With
- Mach 3, Mach 4, and compatible CNC control software
- Step/direction motion control protocols (standard industrial stepper/servo interface)
- 24VDC brake activation circuits and safety interlocks
- Standard industrial servo drives and stepper motor drivers
