Overview
The IDEC AVW401-R is a rugged emergency-stop pushbutton switch designed for industrial control and safety systems. The AVW401-R is a 40mm Emergency-Stop Pushbutton Switch with push lock – turn reset operation. It features a red mushroom button, 1nc contacts, and screw-terminal configuration. It features a chrome plated octagonal locking ring that fastens from the front of the panel. Part of IDEC’s durable TW Series, this switch is built for harsh industrial environments where reliable emergency shutdown is critical.
Key Features
- Chrome plated zinc locking rings, die cast zinc mounting threads, steel anti-rotation rings, and self-cleaning contacts provide long-lasting, industrial strength quality.
- Push-lock-turn-reset operation ensures positive engagement and prevents accidental activation
- Transparent contact windows allow viewing of IDEC’s self cleaning slow-make/slow-break contacts.
- 1NC (Normally Closed) SPST contact configuration
- Red mushroom head (40mm) optimized for emergency-stop applications
- Available with NEMA 1,2,3,3R,3S,4,4X,5,12,13 ratings and UL, CSA, CE approvals.
Technical Specifications
- Maximum Contact Current: 10A
- AC Voltage Rating: 600VAC nominal (440VAC typical)
- DC Voltage Rating: 220VDC nominal
- Contact Configuration: SPST-NC (Single Pole Single Throw – Normally Closed)
- Button Style: Mushroom (40mm head)
- Actuator Type: Push-Lock-Turn-Reset
- Terminal Type: Screw
- Mounting: 22mm panel mount
- Button Color: Red
- IP Rating: IP65
- RoHS Compliant: Yes
Typical Applications
The IDEC AVW401-R is ideal for:
- Emergency-stop stations on machinery and production lines
- Industrial control panels requiring fail-safe shutdown
- Safety interlocks in hazardous area applications
- Manufacturing and heavy equipment operations
- Applications requiring positive push-lock-turn-reset actuation
Compatibility & Replacements
The AVW401-R is part of IDEC’s modular TW Series platform. These devices feature modular construction for maximum flexibility, and snap on, self‑cleaning contact mechanisms, which allow for a wide current rating. Alternative IDEC emergency-stop models include the AYD311N-R (dual contact version) and AVW411-R (1NO/1NC dual contact model). Omron A22NL and A22NN series switches offer comparable functionality in 22mm footprints. Always verify contact configuration and voltage ratings when substituting emergency-stop switches.
