Overview
The Eagle Signal HP50A6 is a precision synchronous motor-driven reset timer from Danaher Specialty Products. This CYCL-FLEX timer delivers reliable on/off control with a 0–30 second adjustable time range, making it a standard choice for automation, process control, and machine sequencing applications. The unit features knob-adjustable timing and a progress pointer for real-time visibility of the countdown cycle.
Key Features
- Synchronous motor-driven mechanism ensures accurate, repeatable timing
- 0–30 second adjustable time range with minimum 1-second setting
- CYCL-FLEX plug-in housing for easy installation and replacement
- Knob-adjustable dial with red progress pointer for remaining time
- 15-terminal ABS molded housing with high impact resistance
- Dual instantaneous and delayed-action contact sets for flexible logic control
- UL Recognized, CSA Certified, and FM Approved
Technical Specifications
The HP50A6 provides robust electrical performance in standard industrial environments:
- Operating Voltage: 120V AC, 60 Hz (standard configuration)
- Contact Rating: 10 Amp
- Time Range: 0–30 seconds
- Motor Drive: Synchronous, 60 Hz
- Housing: 15-terminal ABS molded, impact-resistant
- Contact Configuration: Multiple instantaneous and delayed contacts
- Approvals: UL, CSA, FM
Typical Applications
The HP50A6 timer is widely used in:
- Machine cycle control and sequencing
- Process automation with fixed delay requirements
- Dwell time control in manufacturing equipment
- Pump and motor soft-start delay circuits
- Safety interlocks and shutdown sequences
- Commercial HVAC and refrigeration control systems
Compatibility & Replacements
Compatible With
- Standard 120V AC, 60 Hz industrial control panels
- CYCL-FLEX socket-mounted automation systems
- Relay logic control circuits
- PLC input/output modules as a hardwired timer backup
- Industrial machine control enclosures
Replaces / Drop-In Replacement For
The Eagle Signal HP50A6 directly replaces other 30-second CYCL-FLEX reset timers in the HP5 series. Verify compatibility with your system integrator before ordering to confirm socket type and electrical specifications match your application.
Works With
- CYCL-FLEX standard plug-in sockets
- 120V AC industrial relay panels and control circuits
- Hardwired automation logic (no software/PLC interface)
- Pneumatic and hydraulic control systems requiring timed sequencing
