Overview
The Hoffman TEP4SS exhaust grille is a specialized enclosure ventilation component engineered for TFP series filter fan systems. This 4-inch package measures 6.25×7.33×1.38 inches and is constructed from brushed Stainless 304. The TEP4SS provides filtered exhaust capability with integrated finger guard protection and grille assembly, making it ideal for industrial control enclosures requiring side-mount cooling solutions with limited space.
Key Features
- Material: Type 304 stainless steel with brushed finish for corrosion resistance
- Rating: NEMA 1 enclosure rating with 158°F operating temperature
- Filter Options: Includes washable foam (Type 1) or disposable (Type 12) replacement filters
- Installation: Side-mount design for compact enclosure applications
- Compliance: Includes resources for 2D/3D CAD files and Declaration of Conformity documentation
Technical Specifications
- Part Number: TEP4SS
- Nominal Size: 4-inch
- Dimensions: 6.25″ H × 7.33″ W × 1.38″ D
- Material: Stainless Steel Type 304, Brushed Finish
- NEMA Rating: NEMA 1
- Operating Temperature: 158°F maximum
- Filter Type: Type 1 (washable foam) or Type 12 (disposable)
- Configuration: Exhaust Grille with Finger Guard
- Mounting: Side-mount
- Compliance: RoHS/REACH compliant
Typical Applications
The Hoffman TEP4SS exhaust grille is commonly deployed in:
- Compact industrial control enclosures with thermal management requirements
- Food processing and packaging equipment control systems
- Manufacturing floor electrical cabinets requiring filtered ventilation
- Outdoor enclosures where exhaust protection is needed
- Systems paired with TFP filter fan cooling units in space-constrained environments
Compatibility & Replacements
Compatible With
- TFP series filter fan cooling packages (4-inch nominal size)
- Hoffman industrial enclosures with side-mount capability
- NEMA 1-rated control cabinets
- Washable Type 1 foam filters
- Disposable Type 12 filter media
Replaces / Drop-In Replacement For
This unit is a direct replacement component for the TFP4 series exhaust grille application. To verify compatibility with your specific enclosure model or prior exhaust system, consult your system integrator or enclosure documentation.
Works With
- TFP Side-Mount Fan Systems (4-inch)
- Hoffman TFP Filter Fan packages
- Standard NEMA 1 enclosure cooling networks
- Type 1 and Type 12 industrial filter media
