Overview
The Hoffman C12C12 Consolet (model 59870) is a NEMA Type 12/13, IP65-rated gray (ANSI 61) HMI enclosure made of 14-gauge steel with polyester powder painted finish. The consolet is ideal for mounting small control or instrumentation devices where desirable access requires a 30- or 60-degree surface. This enclosure can be mounted on either of two sides for placement on desktops, pedestals or other flat surfaces, providing flexible positioning for control room, operator station, or field-mounted applications.
Key Features
- Seams continuously welded and ground smooth with no holes or knockouts
- Captivated cover screws thread into sealed wells
- Oil-resistant gasket and adhesive with bonding provision on cover
- Control panel attached with continuous hinge along bottom edge
- Dual-position sloped cover (30° and 60° viewing angles)
- ANSI 61 gray polyester powder paint inside and out over pretreated surfaces
Technical Specifications
- Enclosure Type: Sloped-cover consolet
- NEMA/EEMAC Rating: Type 12, 13
- IP Rating: IP65
- Material: Mild steel, 14-gauge
- Finish: ANSI 61 gray polyester powder coat (inside/out)
- Dimensions: 12.00″ W × 12.00″ D × 9.09″ H
- Cover Type: Hinged, gasketed, captivated screw closure
- Certifications: UL 508A Listed, cUL Listed per CSA C22.2 No. 94
- File No.: E61997
Typical Applications
The Hoffman C12C12 Consolet is widely used for:
- Small PLC or PAC mounting with convenient operator access
- Instrumentation and control device enclosures in manufacturing plants
- Operator station consoles in control rooms
- Field-mounted control enclosures on production lines
- Desktop or pedestal-mounted control panels in industrial environments
- Applications requiring IP65 protection from moisture and dust ingress
Compatibility & Replacements
Compatible With
- Any PLC, PAC, or control device that fits within 12″ × 12″ footprint
- Standard mounting rails and DIN enclosure components
- Industrial control systems requiring NEMA Type 12 protection
- Operator interface devices and small instrumentation modules
- Desktop and pedestal-mount configurations
Replaces / Drop-In Replacement For
The Hoffman C12C12 (59870) is the standard model in the Hoffman C-series mild steel consolet line. Verify compatibility with your system integrator before ordering if replacing an existing unit.
Works With
- Any control platform (Allen-Bradley, Siemens, Mitsubishi, Omron, etc.)
- Dual-mounting positions (30° and 60° surface angles) for flexible integration
- Standard electrical hardware and fastening systems
- Industrial environments with moisture, dust, or light splashing conditions (IP65)
