Overview
The Hoffman DAH8002B is an 800W enclosure heater designed for thermal management in industrial automation and control environments. This thermostatically controlled, fan-driven heater maintains a stable enclosure temperature, protecting critical equipment from temperature extremes, moisture buildup, and corrosion. The DAH8002B features a brushed aluminium finish and interior panel mounting for seamless integration into standard enclosures.
Key Features
- Thermostatically controlled, fan-driven design that draws cool air from the bottom of the enclosure and passes it across the thermostat and heating element
- Thermostat range adjustable from 0 °F to 100 °F (-18 °C to 38 °C)
- Ball bearing fan for reliable long-term operation
- Terminal strip with clamp connector that accepts both solid and stranded wire
- UL 508A Component Recognized
Technical Specifications
The DAH8002B delivers stable, controlled heating for enclosures requiring precise temperature management:
- Power Rating: 800W at 230V AC, 3.3A
- Operating Voltage: 230V AC, 50/60 Hz
- Thermostat Control: 0 to 100 °F (-18 to 38 °C)
- Mounting Type: Interior panel mounting
- Dimensions: 7.5″ H x 4.0″ W x 4.38″ D
- Weight: 6 lb
- Material: Aluminium with brushed finish
- Certifications: UL 508A, CE
Typical Applications
The DAH8002B is suitable for protecting mechanical, electrical and electronic equipment from low temperatures, condensation and corrosion in:
- Industrial control cabinets and electrical enclosures
- PLC and drive installations in cold-weather environments
- Equipment requiring condensation prevention
- Outdoor or unheated facility installations
- Totally-enclosed metal enclosures
Note: These electric heaters are not designed for use in dusty, dirty, corrosive, or hazardous locations.
Compatibility & Replacements
Compatible With
- Standard NEMA/IEC enclosures with interior panel space
- Allen-Bradley and Siemens control cabinets
- Mitsubishi, Omron, and Schneider Electric enclosures
- Any enclosure requiring 230V AC, 50/60 Hz power supply
Replaces / Drop-In Replacement For
- Earlier Hoffman DAH series 800W models at 230V AC
- Direct replacement for equivalent 800W thermostat-controlled enclosure heaters
Works With
- Standard industrial control cabinets and NEMA-rated enclosures
- Thermal management systems requiring manual thermostat control
- Enclosures with 230V AC power distribution
