Overview
The Control Techniques DXE-4120W servo motor is a legacy-design industrial motor engineered for precision motion control applications. This Control Techniques servo motor operates at 230VAC single-phase input with a rated speed of 3000 RPM and delivers continuous torque of 120 lb-in. The splashproof English-mount design with 4-inch frame accommodates wet and washdown environments. Discontinued by the manufacturer, this motor remains a reliable choice for retrofit and replacement applications where exact specifications match your automation system requirements.
Key Features
- 230VAC single-phase input voltage rated
- 3000 RPM synchronized speed with 120 lb-in continuous torque
- Splashproof construction (DXE-4120W designation) for wet environments
- 4-inch frame, English-mount flange configuration
- Integral 24VDC brake option available (verify model suffix for brake configuration)
- Compact footprint suitable for space-constrained automation layouts
Technical Specifications
- Input Voltage: 230VAC
- Rated Speed: 3000 RPM
- Continuous Torque: 120 lb-in
- Frame Size: 4 inch
- Mounting: English flange, foot mount
- Enclosure: Splashproof
- Weight: 26.02 lbs (base motor, varies with brake)
- Brake Option: 24VDC holding brake (on DXE-4120WB variants)
- Manufacturer Status: Discontinued by Control Techniques
- Series: DX Series legacy motors
Typical Applications
The DXE-4120W servo motor is commonly deployed in:
- Industrial packaging and labeling machinery
- Textile and weaving loom drive systems
- Food and beverage processing conveyor systems
- Assembly line indexing and positioning tables
- Gantry and material handling automation
- Retrofit replacements in legacy Unidrive control systems
Compatibility & Replacements
Compatible With
- Control Techniques Unidrive variable frequency drive systems
- Industrial automation controllers supporting 230VAC three-phase or single-phase servo drive architectures
- Standard English-mount motor coupling and mechanical transmission systems
- Legacy industrial equipment originally factory-installed with DX-series motors
Replaces / Drop-In Replacement For
- DXE-4120W (this exact model)
- DXE-4120C (motor-only variant without splashproof coating)
- DXE-4120CB (brake motor variant, if electrical connections and brake voltage match)
- Verify mechanical and electrical compatibility with your system integrator before ordering
Works With
- Control Techniques Unidrive and Mentor AC drives
- 240V single-phase industrial circuits with appropriate motor starter or soft-starter
- Mechanical shaft couplings (flexible or rigid, shaft size 0.75 in. standard)
- Standard servo motor feedback encoders and tachometers (consult control circuit)
