Connecticut Electric UBI 30A Type F Single Pole Circuit Breaker UBIF-30N

Connecticut Electric UBIF-30N 30A Type F Single Pole Circuit Breaker

The Connecticut Electric UBIF-30N is a 30-amp, single-pole circuit breaker designed as a replacement for Federal Pacific Electric (FPE) Type NA (thick) breakers. It is compatible with FPE load centers, ensuring seamless integration into existing electrical systems.

Key Features

• Amperage Rating: 30 Amps
• Voltage Rating: 120 VAC
• Interrupting Capacity: 10,000 AIC
• Type: Type F (Thick)
• Poles: Single-Pole
• Compatibility: Designed for use in Federal Pacific Electric load centers
• Certifications: ETL Listed, CE Certified, UL 489 compliant

Applications

This circuit breaker is suitable for various residential and commercial applications, including:

• Well pumps up to 200 feet
• Bathroom heaters
• 1.5 to 2 HP electric motors

Dimensions

• Length: 3.36 inches
• Width: 1 inch
• Height: 2.55 inches

The UBIF-30N features a plug-in design for easy installation and is constructed with durable materials to ensure long-lasting performance. Its thermal-magnetic trip mechanism provides reliable protection against overloads and short circuits, enhancing the safety of your electrical system.
