Overview
The Bimba DWC-175-2 is a robust double-acting, double-wall pneumatic cylinder engineered for demanding industrial applications. This 1-1/2″ bore unit combines a compact footprint with substantial force output, making it ideal for automation, material handling, and process control. The DWC-175-2 features dual-end cushioning that protects against shock loads and extends component life in high-cycle operations.
Key Features
- Double-wall construction provides superior strength and leak resistance
- Dual-end cushioning for smooth deceleration and reduced impact wear
- Hard chrome-plated rod resists corrosion and rod wear in contaminated environments
- Stainless steel 304 body withstands moisture, salt spray, and chemical exposure
- Standard face mount design fits common cavity and manifold configurations
- Repairable design—seal kits and rod assemblies available for field maintenance
Technical Specifications
- Bore Diameter: 1-1/2″ (38.1 mm)
- Stroke Length: 5″ (127 mm)
- Rod Diameter: 7/16-20 UNF small (male) threaded 1-piece
- Mounting Style: Standard face mounting
- Pneumatic Ports: 2 × 3/8″ NPT (threaded)
- Rated Pressure: 200 psi (13.8 bar)
- Rod Material: Hard chrome-plated steel
- Body Material: Stainless steel 304
- Seals: Buna-N (NBR)
- Lubrication: PTFE-based grease (factory pre-lubricated)
- Cushioning: Both ends (adjustable metering)
Typical Applications
- Packaging and labeling machinery
- Assembly automation and pick-and-place systems
- Press and forming operations
- Material clamping and workholding fixtures
- Food processing and beverage filling equipment
- Semiconductor and clean-room automation
- Woodworking and furniture manufacturing
Compatibility & Replacements
Compatible With
- ISO 4401 5/2 and 5/3 pneumatic directional control valves
- NFPA cavity and subplate manifolds (standard face mount)
- ISO 4414 compressed air distribution systems (200 psi max)
- Pneumatic regulators and inline silencers with 3/8″ NPT ports
- Pneumatic flow control valves and shuttle valves
Replaces / Drop-In Replacement For
- Bimba DW-175-2 (same bore/stroke without dual-end cushioning)
- Standard face-mount 1-1/2″ bore cylinders from other manufacturers in equivalent cavity
Works With
- ISO 4414 pneumatic control standards
- NFPA (National Fluid Power Association) manifold platforms
- Parker, SMC, Festo, and other compatible manifold suppliers
- Pneumatic soft-starters and acceleration valves
- Pressure transducers and flow sensors for feedback integration
