ATV312HU15M2 – Schneider Electric – Altivar Variable Speed Drive
General Purpose AC Drives
ATV312HU15M2 – Schneider Electric – Altivar Variable Speed Drive
Price
$495.00
SKU
Condition
Availability
C-4-7-385
Used
1 in stock
Free Shipping
On orders over $50
Easy Returns
30-day return policy
Secure Payment
100% secure
| Condition | Used |
|---|---|
| Manufacturer | Schneider Electric |
| Part Number | ATV312HU15M2 |
| Product Series | Altivar 312 |
| Rated Power | 1.5kW (2 HP) |
| Input Supply | Single-phase, 200–240V AC |
| Output Frequency Range | 0–500 Hz |
| Output Current (Max) | 8A |
| Apparent Power | 3.2 kVA |
| Communication Protocols | Modbus RTU, CANopen (standard); optional: DeviceNet, Profibus DP, Modbus TCP |
| Enclosure Rating | IP20/IP21/IP31/IP41 |
| Operating Temperature | −10 to +50°C (with cover); −10 to +60°C (without) |
| Dimensions (W×D×H) | 105 × 152 × 143 mm |
| Certifications | UL Listed, CSA Certified, CE Marked, RoHS Compliant |
| Motor Type | Asynchronous AC motors (1.5kW max) |
| Switching Frequency | 4 kHz (nominal) |
