Overview
The AMP 749805-3 (D25PCTKPC) is a shielded crimp snap kit designed for 25-position D-sub connector assemblies. The kit includes unassembled components with crimp termination and is commonly used in industrial control panels, telecommunications equipment, and computer peripherals requiring robust shielded connections.
Key Features
- 25-position D-sub connector kit
- Shielded design for noise immunity and EMI protection
- Crimp termination for secure wire attachment
- Unassembled kit format—ready for field termination
- Steel shell with tin-plated contacts for corrosion resistance
- Compatible with standard D-sub tooling and accessories
Technical Specifications
- Part Number: AMP 749805-3
- Catalog Number: D25PCTKPC
- Connector Type: D-Sub, 25-position
- Termination Style: Crimp
- Shell Material: Steel with tin plating
- Contact Plating: Tin-plated copper
- Housing Material: Polyester/nylon GF (glass-filled)
- Shielding: Yes
- Kit Configuration: Unassembled
- Manufacturer: AMP (TE Connectivity)
Typical Applications
- Industrial control and automation systems
- Telecommunications equipment and patch panels
- Computer peripherals and legacy equipment
- Data acquisition systems
- Laboratory instrumentation
- Equipment requiring EMI/RFI shielding
Compatibility & Replacements
Compatible With
- Standard D-sub 25-pin connector systems
- DB25 equipment and enclosures
- Industrial automation panels
- Serial communication interfaces (RS-232 and legacy systems)
- Standard crimp termination tools
Replaces / Drop-In Replacement For
- Other AMP 25-position D-sub shielded kit variants
- Generic 25-position D-sub unassembled kits
- Note: Verify compatibility with your system integrator before ordering to ensure correct connector type and pin configuration.
Works With
- Standard D-sub crimp tools (AMP/Tyco, Molex, etc.)
- Wire gauges: 20–24 AWG (typical for connector family)
- Industrial cabinet and panel mounting systems
- Standard D-sub cable assemblies
