Overview
The Allen-Bradley 800H-R6AY /G pushbutton is a 30mm momentary pushbutton engineered for demanding industrial automation environments. Part of the industry-proven 800H series, this non-illuminated operator delivers dependable tactile feedback and electrical switching for control panel applications. Designed and constructed to perform in demanding industrial environments, the 800H meets NEMA Type 4/4X/13 ratings for indoor/outdoor use, making it suitable for machine automation, process control, and emergency stop circuits.
Key Features
- Red booted head with 30mm momentary action for intuitive user operation
- Type 4/4X/13 NEMA-rated plastic enclosure compatible with industrial washdown and outdoor installations
- Supports vibration ratings of 10 to 2000 Hz and 0.06 inches of displacement/10 G peak-to-peak, with shock tolerance up to 100 g
- Non-illuminated design with screw-terminal connections for 18–14 AWG wire
- Mechanical lifespan rated for millions of actuations in production environments
Technical Specifications
The pushbutton is configured with 1 Normally Open (N.O.) and 1 Normally Closed (N.C.) contact option. Electrical ratings depend on application voltage and are available in common industrial standards. Wire connections use standard screw terminals compatible with 18–14 AWG conductors. The 30mm mounting hole accommodates standard NEMA panel cutouts. Operating temperature range is from −25°C to +60°C, with storage capability to −40°C to +80°C. All contact materials meet industrial switching standards for both AC and DC applications.
Typical Applications
This pushbutton is widely deployed in:
- Machine start/stop control circuits
- Emergency stop (E-stop) stations and pilot devices
- Process control systems requiring tactile feedback
- Industrial automation control panels with Type 4/4X/13 rating requirements
- Washdown and harsh-environment installations
Compatibility & Replacements
The 800H-R6AY /G is part of the Allen-Bradley Bulletin 800H/800T 30mm push button family. Direct replacements and functionally equivalent models within the 800H series share the same 30mm mounting footprint and NEMA ratings. Upgrade to illuminated variants (800H-R6L) or select alternative actuator colors (green, black, blue, yellow, orange, white) from the same bulletin for flexible panel design. Consult your local Allen-Bradley distributor or Rockwell Automation sales office for application-specific contact block configurations, optional legend caps, and specialized environmental ratings.
