Overview
The Allen-Bradley 800FP-P3PN5G is a compact 22mm pilot light engineered for clear visual status indication in industrial control cabinets and panel-mounted applications. This green LED unit operates at 120V AC and features a plastic round operator with integrated latch mechanism, making it a drop-in solution for equipment requiring reliable, at-a-glance hazard and operational status alerts. Built to meet demanding industrial performance standards, this component is part of Allen-Bradley’s proven 800F family of pushbuttons and indicators.
Key Features
- Green LED illumination — integrated LED module provides bright, low-power visual indication
- 22mm panel cutout — compact form factor fits standard industrial control panels
- Plastic round operator — rugged construction with latch-only mounting (no contact blocks)
- 120V AC rated — direct AC line power operation for straightforward integration
- IP66 enclosure rating — sealed design resists dust and water ingress in harsh environments
- Latch mechanism — secure panel mounting without additional hardware
Technical Specifications
- Part Number: 800FP-P3PN5G
- Manufacturer: Allen-Bradley / Rockwell Automation
- Series: 800F Pilot Light (Bulletin 800FP)
- Voltage Rating: 120V AC
- Lamp Type: LED (integrated module)
- Lens Color: Green
- Panel Cutout Diameter: 22.5 mm (22 mm standard)
- Material: Plastic operator with plastic latch mount
- Mounting Type: Panel screw terminal
- Operator Shape: Round flat
- Enclosure Rating: IP66 (Types 4/4X/13)
- Weight: 0.10 lbs per unit
- Certifications: CUL, UL, CE, CSA, CCC, KC, MARINE
Typical Applications
- Industrial machine control panels requiring clear status indication
- Process automation systems with visual hazard alerting
- Manufacturing equipment cabinets for operator feedback
- Wet and dusty environments where IP66 sealing is required
- Control system status signals (ready, running, fault, standby)
Compatibility & Replacements
Compatible With
- Allen-Bradley 800F family pushbutton and indicator assemblies
- Standard industrial control panels with 22mm mounting holes
- AC power systems rated 120V nominal
- Panel-mounted indicator applications in Rockwell Automation systems
Replaces / Drop-In Replacement For
- Previous-generation 800FP green pilot lights (verify exact model with system integrator)
- Direct replacement for existing 800FP-P3PN5G inventory
Works With
- Allen-Bradley ControlLogix, CompactLogix, and SLC 500 control systems
- Rockwell Automation panel design and layout workflows
- Standard AC power distribution and circuit breaker systems
- All 800F series accessories and modular components
