Overview
The Harting 09310062701 Han 6 HSB-BU female connector insert is a rectangular heavy-duty power connector designed for industrial automation, machinery, and control panel applications. This insert is part of the Han® HsB series and provides reliable electrical connections for circuits requiring high current capacity and robust mechanical contact.
Key Features
- High Current Rating: Rated for 35A at 690V (L-L) / 400V (L-E), suitable for three-phase power distribution
- Screw Terminal Design: Supports wire cross-sections up to 6 mm² for secure, accessible wiring
- 6+PE Contacts: Six main poles plus protective earth contact for balanced three-phase systems
- Polycarbonate Insert: UL94-V0 flammability rating for fire safety in enclosed environments
- Heavy-Duty Construction: Copper alloy contacts with silver plating ensure low contact resistance and corrosion resistance
- 16B Series Housing Compatibility: Integrates with standard Han 16B hoods and housings
Technical Specifications
- Contact arrangement: 6+PE (6 power + 1 protective earth)
- Rated current: 35A
- Rated voltage: 400V (L-E) / 690V (L-L)
- Test voltage: 6 kV
- Wire cross-section: 1.4 – 6 mm² (10–16 AWG)
- Termination: Screw terminals
- Insert material: Polycarbonate (UL94-V0)
- Contact material: Copper alloy, silver-plated
- Gender: Female
- Series: Han® HsB
- Manufacturer part number: 09310062701
Typical Applications
The Han 6 HSB-BU insert is commonly deployed in:
- Three-phase power distribution in control cabinets and panels
- Heavy machinery and industrial automation equipment connections
- Modular control system interconnects requiring frequent mating/unmating
- High-amperage motor and drive connections
- Industrial sensor and actuator networks with power requirements
Compatibility & Replacements
Compatible With
- Han® 16B series connector housings and hoods
- Han HsB male connector inserts (complementary 6-pole + PE versions)
- Industrial control panels and machine tool installations
- Three-phase distribution systems rated 400/690V
Replaces / Drop-In Replacement For
- This is the original Harting part; verify compatibility with existing hoods/housings before substitution
- Harting SKU: HAN-6-HSB-BU
Works With
- Standard industrial connector panel-mount fixtures
- Cable assemblies with 35A three-phase terminals
- Control systems requiring robust power interconnects
