Overview
The Telemecanique ZCK-D06 is a metal limit switch operating head designed for integration with Telemecanique XC standard series limit switch bodies. This cat’s whisker spring rod-type limit switch head is used with ZCKS-series bodies in making and breaking electrical connections. The multi-directional design enables activation from any approach angle, making it ideal for flexible mounting configurations in industrial control and automation systems.
Key Features
- Multi-directional actuation: Responds to movement from any direction for flexible application mounting
- Cat’s whisker spring return: Metal spring-loaded actuator design provides reliable tactile feedback and repeatable switching action
- IP65 rating: Protection from dust and water for harsh industrial environments
- Compact metal construction: Durable metal frame and actuator for long service life
- Top plunger position: Head features a top plunger position and spring return for intuitive mounting and operation
- No positive opening: Designed for standard switching applications without safety-rated positive opening mechanics
Technical Specifications
- Part Number: ZCK-D06 (ZCKD06)
- Manufacturer: Telemecanique Sensors (Schneider Electric)
- Head Type: Multi-directional limit switch head
- Actuator Type: Cat’s whisker spring return metal
- Approach: Multi-directional approach by any moving part
- Head Material: Metal
- Operating Temperature Range: -40 to 70°C storage temperature
- Protection Rating: IP65 (dust and water resistant)
- Switch Function: Without positive opening
- Certifications: UL Listed, CSA Certified, CE Certified, RoHS Compliant
- Physical Form Factor: Standard 3-inch length limit switch head
Typical Applications
The Telemecanique ZCK-D06 is widely used in:
- Conveyors, packaging machinery, and material handling equipment
- Machine tool limit and end-of-travel sensing
- Assembly line position detection and safety interlocks
- Manufacturing automation requiring multi-directional approach actuation
- Industrial systems demanding IP65 environmental protection
- OEM equipment replacement and retrofit applications
Compatibility & Replacements
Compatible With
- Compatible with XCKM, XCKL, and XCKS limit switch bodies
- Telemecanique XC standard series limit switch systems
- Standard industrial automation control systems using snap-action switches
- 24 VDC and 120/240 VAC rated switch circuits
Replaces / Drop-In Replacement For
- Alternate Part No. ZCKD06
- Earlier generation multi-directional limit switch heads in XC standard series
- Verify exact compatibility with your system integrator or OEM documentation before ordering
Works With
- Telemecanique limit switch body assemblies (ZCKL, ZCKJ, XCKL series)
- Standard industrial electrical control systems and PLC I/O modules
- Pneumatic and hydraulic automation equipment with position sensing requirements
- Programmable logic controllers (PLCs) and motion control systems
