Overview
The Woodhead 50-1653 L16-20R receptacle is a NEMA-standard industrial electrical outlet rated for 20A at 480V 3-phase service. This unit combines a flush-mount locking receptacle with an integrated cover that protects the connector from environmental hazards, dust, and accidental contact. Designed for industrial automation, control systems, and power distribution applications where reliable, code-compliant electrical connections are critical.
Key Features
- NEMA L16-20R locking receptacle—secure, tamper-proof connection
- 20A, 480V 3-phase rating—suitable for heavy-duty industrial loads
- Integrated protective cover—shields connector from environmental exposure
- Flush-mount installation—space-efficient for wall or enclosure mounting
- Durable industrial construction—built for continuous industrial service
- 3-pole 4-wire grounding system—meets modern electrical safety standards
Technical Specifications
Electrical Ratings
- Voltage: 480V AC
- Current: 20A
- Phase: 3-phase
- Poles: 3-pole, 4-wire with ground
- Configuration: NEMA L16-20R (female receptacle)
Physical & Installation
- Mounting: Flush-mount with cover
- Housing: Industrial-grade thermoplastic
- Terminal Type: Screw terminals
- Color: White
Typical Applications
The Woodhead 50-1653 is used in:
- Industrial motor control centers and distribution panels
- Heavy equipment and machinery power feeds
- Manufacturing and automation facilities
- Temporary and portable power distribution systems
- Industrial plant upgrades and maintenance applications
Compatibility & Replacements
Compatible With
- NEMA L16-20P plugs (male connectors)
- Standard 480V 3-phase industrial power systems
- Motor control enclosures and distribution cabinets
- Industrial automation equipment requiring three-phase power
Replaces / Drop-In Replacement For
The Woodhead 50-1653 receptacle is compatible with standard NEMA L16-20R receptacle applications. Verify compatibility with your specific control system or equipment before ordering.
Works With
- NEMA L16-20P mating plugs
- Standard 480V 3-phase electrical distribution systems
- Industrial control wiring and enclosures meeting NEC standards
