Overview
The Unitrode CGA0472ZCZ ceramic capacitor is a Z5U-rated component designed for general-purpose energy storage and filtering applications in industrial and commercial electronics. With a capacitance value of 4700pF and a working voltage of 25V, this used unit offers cost-effective functionality for retrofit and repair applications where tight component tolerances are not critical.
Key Features
- Capacitance: 4700pF (0.0047µF)
- Z5U dielectric material for reliable performance across temperature variations
- 25V voltage rating suitable for low-voltage circuit protection
- Asymmetric tolerance (±80%-20%) typical of Z5U grade components
- Non-polarized ceramic construction allows flexible circuit placement
- Compact form factor for dense PCB layouts
Technical Specifications
The CGA0472ZCZ meets the dimensional and electrical characteristics expected of legacy Unitrode ceramic capacitors. Z5U dielectrics are rated for temperature stability across industrial ranges, making them suitable for general filtering, coupling, and decoupling functions where exact value matching is not required.
Typical Applications
- AC line filtering and EMI suppression
- Coupling and decoupling in audio circuits
- Low-frequency filtering applications
- General-purpose energy storage in legacy equipment
- Industrial control panel retrofits and repairs
Compatibility & Replacements
Compatible With
- Legacy industrial control circuits and PLCs
- Analog audio and signal conditioning circuits
- Low-voltage power supply filtering stages
- General-purpose PCB layouts rated for 25V or less
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. Z5U ceramic capacitors with matching 4700pF/25V ratings from other manufacturers may serve as alternatives, but the asymmetric tolerance specification should be confirmed for your application.
Works With
- Standard PCB assembly and rework equipment
- Manual circuit repair and prototyping
- Through-hole and surface-mount compatible designs (verify mounting style)
- Industrial electrical test and measurement instruments
