Overview
The F8-108 air filter is a paper filter element designed as a direct replacement for Stoddard compressed air intake systems. This replacement filter element features high-efficiency pleated media construction and is engineered to remove dust, oil, water vapor, and airborne contaminants that can damage or reduce the efficiency of air compressors and pneumatic equipment. With a nominal capacity of 135 CFM, it fits standard Stoddard filter housings and maintains maximum surface area under operating pressure.
Key Features
- High-efficiency pleated paper media for effective particulate removal
- Nominal airflow capacity of 135 CFM
- Durable construction designed to hold shape under pressure
- Direct replacement for original Stoddard F8-108 housings
- Serviceable element — can be cleaned by rapping or reverse compressed air flow (up to 75 PSIG max)
- Standard mounting configuration compatible with Stoddard filter housings
Technical Specifications
| Nominal CFM Capacity | 135 CFM |
| Outer Diameter (OD) | 6.875″ |
| Inner Diameter (ID) | 4.75″ |
| Height | 4″ |
| Weight (approximate) | 2 lbs (0.91 kg) |
| Media Type | Pleated paper |
| Maximum Service Pressure | 75 PSIG (for cleaning) |
| Application | Compressed air intake filtration |
| Compatible Series | Stoddard F8 series |
Typical Applications
- Rotary screw air compressors
- Reciprocating air compressors
- Rotary vane air compressors
- Industrial pneumatic systems
- Roots blowers and vacuum pump intake protection
- Manufacturing facilities requiring clean compressed air supply
Compatibility & Replacements
Compatible With
- Stoddard F8 series filter housings
- Standard 4″ height filter cup assemblies with 6.875″ OD envelope
- Compressed air systems rated for 135 CFM intake flow
- Pneumatic tools and equipment requiring filtered intake air
Replaces / Drop-In Replacement For
- Stoddard F8-108 original equipment filter elements
- OEM Stoddard intake filters in F8 series housings
Works With
- Stoddard silencer filter housings
- Standard pneumatic system configurations
- Air intake applications up to 135 CFM
- Compressed air systems using Stoddard-compatible filter cups
