Overview
The TYOHM RSS 3W 30Ω ±5% metal oxide film resistor is a passive component engineered for demanding electronic applications. Metal oxide film construction provides excellent stability, low noise, and consistent resistance characteristics across temperature variations, making it ideal for industrial control systems, power supplies, and measurement circuits.
Key Features
- Metal oxide film construction for thermal stability and low temperature coefficient
- 3-watt power rating with ±5% tolerance for general-purpose circuit design
- Reliable axial-lead component for through-hole PCB mounting
- Wide operating temperature range typical of industrial-grade resistors
- RoHS compliant for modern manufacturing standards
Technical Specifications
- Resistance Value: 30 Ω
- Power Rating: 3 W
- Tolerance: ±5%
- Construction Type: Metal Oxide Film
- Terminal Style: Axial Leads
- Mounting: Through-Hole PCB
- Manufacturer: TYOHM
- Series: RSS
Typical Applications
- Industrial power supplies and switching regulators
- Current sensing and load management circuits
- Audio and signal conditioning amplifier networks
- Test and measurement instrumentation
- Protective circuit networks in control systems
Compatibility & Replacements
Compatible With
- Through-hole PCB designs requiring 3-watt power dissipation
- Industrial control and automation circuits
- Power supply topologies requiring load resistors
- Signal conditioning and filtering applications
Replaces / Drop-In Replacement For
- Other TYOHM RSS-series 3W 30Ω resistors
- Generic metal oxide film 3W 30Ω ±5% resistors from comparable manufacturers
- Verify compatibility with your system integrator before ordering for critical applications
Works With
- Standard PCB assembly and rework equipment
- Industrial temperature soldering processes
- Through-hole component automation
- Quality assurance and in-circuit testing systems
