Overview
The Togi PCN-2M50A is a Japanese-manufactured interface terminal block from Toyogiken, designed for secure, error-proof wiring in industrial control systems. This 50-position connector terminal features a compact 40 mm wide body and integrated MR male connector, delivering reliable signal distribution in automation applications.
Key Features
- 50-position MR male connector for signal distribution
- Compact 40 mm body width—slimmer than standard DIN rail designs
- Integrated terminal and connector reduce mis-wiring and assembly errors
- 1-to-1 terminal-to-connector mapping enables flexible circuit design
- Lever-type removal mechanism—no tools required for DIN rail installation
- Compatible with both DIN rail and direct panel mounting
Technical Specifications
- Rated Voltage: 125V AC
- Rated Current: 1A per pole
- Number of Poles: 50
- Connector Type: MR male
- Body Width: 40 mm
- Length: 12.00 inches
- Width: 9.00 inches
- Depth: 6.00 inches
- Weight: 0.90 lbs
- Mounting: DIN rail and direct mount compatible
Typical Applications
- PLC and motion controller signal distribution
- Industrial machinery control wiring
- Machine tool automation interfaces
- Process control and instrumentation
- Laboratory and test equipment signal routing
Compatibility & Replacements
Compatible With
- Toyogiken (Togi) control systems and interfaces
- Standard DIN 35 rail mounting
- Industrial automation platforms requiring 50-pole connectors
- MR connector-compatible harnesses and cables
Replaces / Drop-In Replacement For
The PCN-2M50A is a base model in the Toyogiken PCN series. Verify exact replacement compatibility with your existing connectors and terminal block model before ordering, as Togi offers variant models (PCN-2M50B, PCN7-2M50A) with different connector types.
Works With
- MR male connector harnesses (standard pinout verification recommended)
- DIN rail-mounted control enclosures
- Panel-mounted terminal assemblies
- Standard industrial control wiring practices
