<h2>Overview</h2>
<p>The <strong>Telemecanique GV2-M06</strong> is a three-pole thermal magnetic circuit breaker designed for motor protection and manual control applications. This compact DIN rail-mounted unit combines overload and short-circuit protection in a single device, making it suitable for small to medium motor circuits. Manufactured by Schneider Electric under the Telemecanique brand, the GV2-M06 delivers reliable protection with adjustable trip characteristics.</p>
<h2>Key Features</h2>
<ul>
<li>Adjustable thermal overload trip range from 1.0 to 1.6A</li>
<li>Thermal magnetic protection for motor circuits</li>
<li>Manual motor starter/controller with push-button operation</li>
<li>DIN rail mounting for standard industrial enclosures</li>
<li>Compact footprint (45mm width)</li>
<li>Reliable contact position indication</li>
</ul>
<h2>Technical Specifications</h2>
<ul>
<li><strong>Voltage Rating:</strong> 690VAC (600VAC UL rated)</li>
<li><strong>Frequency:</strong> 50/60 Hz</li>
<li><strong>Current Rating (Trip Range):</strong> 1.0-1.6A adjustable</li>
<li><strong>Poles:</strong> 3 (three-phase)</li>
<li><strong>Breaking Capacity:</strong> 12kA AC</li>
<li><strong>Mounting Type:</strong> DIN Rail (35mm symmetrical)</li>
<li><strong>Operating Temperature:</strong> -20 to +60°C</li>
<li><strong>Dimensions:</strong> 45mm W × 78.5mm D × 89mm H</li>
<li><strong>Weight:</strong> 0.60 lbs</li>
<li><strong>Standards:</strong> UL508, CSA C22.2, IEC 60947-2, IEC 60947-4-1, EN 60947-1</li>
</ul>
<h2>Typical Applications</h2>
<ul>
<li>Motor protection in industrial machinery and equipment</li>
<li>Manual motor starter for fractional-horsepower motors</li>
<li>Thermal overload and short-circuit protection</li>
<li>Low-voltage distribution panels and control cabinets</li>
<li>Machine tool and automation equipment circuits</li>
</ul>
<h2>Compatibility & Replacements</h2>
<h3>Compatible With</h3>
<ul>
<li>Standard 35mm DIN rail mounting systems</li>
<li>Three-phase AC motor circuits 400-690VAC</li>
<li>Schneider Electric TeSys GV2 series ecosystem</li>
<li>Optional auxiliary contacts (GV2AN11 compatible)</li>
</ul>
<h3>Replaces / Drop-In Replacement For</h3>
<ul>
<li>GV2M06 (alternate part designation)</li>
<li>GV2ME06 (IEC version with same ratings)</li>
<li>Telemecanique thermal magnetic motor starters in the 1-1.6A range</li>
</ul>
<h3>Works With</h3>
<ul>
<li>Manual push-button control stations</li>
<li>Auxiliary contact modules for extended control circuits</li>
<li>DIN rail-mounted control systems and distribution blocks</li>
<li>Standard industrial control enclosures</li>
</ul>
