Overview
The Square D 9007T10 limit switch operating head is a precision rotary actuator for the 9007C heavy-duty industrial limit switch series. This component operates as a stand-alone actuating head and integrates seamlessly with 9007C switch bodies, enabling bidirectional (clockwise and counterclockwise) actuation with automatic spring return to neutral. Engineered for harsh industrial environments, the 9007T10 delivers reliable snap-action switching and precision control in machinery, conveyors, packaging equipment, and plant automation systems.
Key Features
- Rotary spring-return head—automatic reset to neutral position without manual intervention
- Bidirectional (CW+CCW) operation—controls contacts in both clockwise and counterclockwise directions
- Cast zinc diecast construction—corrosion-resistant housing rated for harsh industrial service
- Standard pretravel—6° pretravel ensures positive and repeatable contact engagement
- Oil-tight design—sealed against temporary submersion and epoxy-encapsulated housing
- UL-listed and CSA-certified—meets North American electrical safety standards
Technical Specifications
- Contact Type: Snap-action, spring return
- Actuator Type: Rotary head
- Operating Direction: Clockwise + Counterclockwise (CW+CCW)
- Pretravel: Standard (6°)
- Housing Material: Zinc diecast
- Operating Temperature: -20 to +185 °F (-29 to +85 °C)
- Protection Rating: IP67 (oil-tight enclosure)
- Certifications: UL-listed, CSA-certified
- Body Series: 9007C (heavy-duty semimodular, 39mm metal body)
Typical Applications
- Conveyor belt position control and limit detection
- Machinery start/stop sequencing based on actuator position
- Rotary valve and damper control
- Packaging and material handling equipment
- Machine tool spindle and turret positioning
- Industrial automation and process control systems requiring bidirectional sensing
