Overview
The Sprague 196P274910S2 Vitamin Q paper-in-oil capacitor combines military-grade reliability with classic analog characteristics. Rated for 125°C operation, this 1000VDC unit represents vintage component engineering from the 1950s–1970s era. Style 2 parts are housed in bare metal cans, providing proven hermetic sealing and long-term stability in demanding environments.
Key Features
- Military specification construction (MIL-C-25A) ensures stringent reliability and performance standards
- Paper-in-oil dielectric provides stable capacitance retention and low leakage over decades
- 125°C rated temperature range accommodates high-temperature circuit applications
- Bare metal can design with sealed hermetic construction resists moisture ingress
- New old stock condition with factory testing verification
Technical Specifications
The 196P274910S2 features a sealed metal housing engineered to withstand demanding military and industrial requirements. Capacitors tested have been precisely within the manufacturer’s tolerance rating, ensuring performance consistency. Extended foil design in the 196P series optimizes capacitance stability and low ESR characteristics.
Typical Applications
- Military and aerospace RF/analog circuits requiring 1000VDC bias
- High-voltage industrial control systems and switching supplies
- Audio amplifier coupling and tone circuits (vintage equipment restoration)
- Test and measurement instrumentation
- Power conversion and distribution equipment
Compatibility & Replacements
Compatible With
- Military and defense electronics (MIL-SPEC rated systems)
- Vintage tube amplifier and radio restoration projects
- High-voltage industrial control circuits
- Audio equipment requiring 1000VDC capacitors
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator or application engineer before ordering, as this is a vintage military surplus component. Equivalent 1000VDC capacitors from Sprague’s 196P series may be substituted where physical dimensions and lead configuration match.
Works With
- High-voltage DC power supplies (up to 1000VDC rating)
- Analog and RF circuit designs requiring paper-in-oil dielectrics
- Military equipment requiring MIL-SPEC component certification
- Legacy industrial and telecommunications systems
