Overview
The Solium 31126 electronic CFL ballast is a reliable power supply for compact fluorescent lighting systems requiring single-lamp configurations. This ballast is rated for 26W or 32W 4-pin CFL lamps at 120V input and uses rapid start technology for immediate lamp ignition without delay. Electronic ballasts of this type offer superior energy efficiency, reduced flicker, and quieter operation compared to magnetic alternatives, making them the preferred choice for commercial and industrial facilities seeking to maintain or upgrade their lighting infrastructure.
Key Features
- Electronic design: Solid-state circuitry provides smooth operation, minimal acoustic noise, and better energy efficiency than magnetic ballasts
- Dual-wattage capability: Operates both 26W and 32W 4-pin CFL lamps, offering flexibility in lamp selection
- Rapid start ignition: Instant lamp startup without preheating or visible warm-up delay
- Single-lamp configuration: Designed for straightforward one-lamp fixture applications
- 120V operation: Standard North American residential and commercial line voltage
- Compact form factor: Space-efficient design suitable for recessed fixtures and standard fixture enclosures
Technical Specifications
- Input Voltage: 120V AC, 60 Hz
- Lamp Wattage: 26W or 32W 4-pin CFL
- Lamp Configuration: Single lamp (1-lamp)
- Ballast Type: Electronic, programmed rapid start
- Lamp Base: 4-pin (G24q-2 or G24q-3)
- Operating Frequency: High-frequency (approx. 20 kHz+)
- Power Factor: Greater than 0.90 (typical electronic ballast)
- Certification: UL listed, FCC Part 18 compliant (typical)
- Mounting: Feet or wire harness attachment
- Operating Temperature Range: 0°C to 50°C (standard)
Typical Applications
- Commercial office recessed downlights and surface-mount fixtures
- Industrial facility task and general illumination
- Retail and hospitality lighting systems
- Educational and institutional building lighting maintenance
- Single-lamp fixture replacement in existing installations
Compatibility & Replacements
Compatible With
- 26W 4-pin CFL lamps (G24q-2 base)
- 32W 4-pin CFL lamps (G24q-3 base)
- Standard recessed and surface-mount CFL fixture housings
- 120V AC line voltage systems in North America
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. CFL ballast cross-references depend on exact fixture wiring and lamp base specifications. Common electronic ballast replacement models in this category include Advance SmartMate (ICF-2S26-H1-LD series), GE ProLine, Fulham RaceHorse, and Universal Triad units rated for single 26W/32W 4-pin operation at 120V.
Works With
- 4-pin CFL lamp bases: G24q-2, G24q-3
- Rapid start ballast-compatible fixture wiring (red/blue lamp leads, yellow jumper)
- Standard 120V AC electrical service
