Overview
The SMC CP95SDB50-315 is a double-acting pneumatic cylinder built to ISO profile standards and VDMA specifications. With a 50mm bore and 315mm stroke, this cylinder delivers consistent performance in industrial automation applications. Manufactured by SMC, the world’s largest pneumatic components producer, this unit is engineered for reliability in repetitive motion control systems.
Key Features
- Double-acting design for controlled forward and reverse motion
- ISO profile construction (VDMA compliant) for standard system integration
- 50mm piston bore with 315mm stroke length
- Compact mounting footprint with standard port configurations
- Durable construction suitable for high-cycle industrial environments
- Compatible with SMC standard pneumatic system components
Technical Specifications
- Bore Size: 50 mm
- Stroke Length: 315 mm
- Cylinder Type: Double-Acting
- Profile Standard: ISO / VDMA Specification
- Port Connection: Standard pneumatic
- Maximum Operating Pressure: 1.0 MPa (typical for SMC CP95 series)
- Series: CP95 Profile Cylinder
- Model: CP95SDB50-315
- Condition: New – No Box
Typical Applications
- Assembly line automation and material handling
- Packaging machinery positioning and transfer systems
- Press and workholding clamp applications
- Linear motion control in automated production lines
- OEM equipment integration requiring standardized cylinders
- Replacement cylinders in existing pneumatic systems
Compatibility & Replacements
Compatible With
- SMC pneumatic control systems and manifolds
- VDMA-specification pneumatic networks
- ISO profile cylinder mounting systems
- Standard 5/2 and 5/3 solenoid valve circuits
- Pneumatic pressure regulators and filter units
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering for specific replacement applications. ISO profile cylinders with 50mm bore and 315mm stroke from other manufacturers may share mounting patterns; consult technical documentation to confirm.
Works With
- SMC pneumatic circuit design software
- VDMA standardized pneumatic components
- ISO 4401 valve mounting standards
- Standard industrial air compressors (1.0 MPa maximum)
- Pneumatic control valve systems (5-port, 2/3-position)
