Overview
The Traceable 5004 4-channel big digit timer is a microcomputer-controlled laboratory timer delivering independent countdown, count-up, and stopwatch functions across four simultaneous channels. A large 3/4″ high display permits viewing from across the lab. An individually serial-numbered Traceable® Certificate is provided from the Traceable ISO 17025 calibration laboratory accredited by A2LA, indicating traceability to standards provided by NIST. Built-in memory recall ensures repeatability in routine testing and quality assurance workflows.
Key Features
- Four Independent Channels: All 4 channels may be used simultaneously in any combination to count down or count-up (stopwatch).
- Memory Recall: At the touch of a button the remarkable memory returns the display to the previously programmed countdown time.
- Extended Timer Range: Set any countdown time from 99 hours, 59 minutes, 59 seconds to 1 second.
- Audible Alarm: Extra-loud, high-decibel alarm sounds for 1 minute or may be silenced manually.
- Integrated Clock: Additional features include stopwatch, time-out, and time of day clock.
- Magnetic Mounting: Magnetic back allows timer to be placed on any metal surface such as incubators or water baths.
Technical Specifications
- Model: 5004
- Channels: 4 independent
- Timing Range: 1 second to 99 hours, 59 minutes, 59 seconds
- Time Resolution: 1-second increments
- Display Type: Digital LCD, large digit format
- Display Size: 3/4″ high digits
- Operating Functions: Countdown, count-up, stopwatch, clock, alarm
- Alarm Type: High-decibel audible (1-minute duration)
- Dimensions: 2.75″ × 2.5″ × 0.5″
- Weight: 2 oz
- Calibration: NIST-traceable (ISO 17025, A2LA accredited)
- Included Accessories: Magnetic clip, stand, case, batteries, Traceable Certificate
- Mounting Options: Magnetic back, stand, clip attachment
Typical Applications
The Traceable 5004 is widely used in laboratory and industrial environments where calibrated timing with documentation is required:
- Quality assurance and process validation testing
- Pharmaceutical and biomedical research laboratories
- Incubator and water bath monitoring
- Compliance-driven manufacturing (FDA, ISO, GLP)
- Multi-parameter simultaneous test operations
- Educational and training environments requiring traceable measurement
Compatibility & Replacements
Compatible With
- Laboratory incubators (magnetic mounting)
- Water baths and thermal chambers
- Fermentation vessels and bioreactors
- Any metal test bench or equipment surface
- Compliant with NIST Standard Reference Materials (SRM) validation protocols
Replaces / Drop-In Replacement For
The Traceable 5004 serves as a direct replacement for the Control Company 5004. No other multi-channel 4-timer models directly substitute without functional capability loss.
Works With
- ISO 17025 calibration documentation systems
- GLP (Good Laboratory Practice) compliance workflows
- FDA 21 CFR Part 11 traceability audits
- NIST accreditation records (A2LA)
- Laboratory Information Management Systems (LIMS) for archival of calibration certificates
