Overview
The Ashcroft receiver gauge 25 PSI is an industrial-grade pressure measurement instrument designed for compressed air receiver tanks and pneumatic systems. This Duragauge model delivers robust, accurate readings in applications where reliability is critical. The gauge features a 0-100 PSI dial range with a maximum input pressure rating of 25 PSI, making it suitable for low-to-medium pressure monitoring in manufacturing, maintenance, and service environments.
Key Features
- Duragauge Construction: Bronze tube with brass socket brazed design resists corrosion and mechanical shock
- Clear 0-100 dial marking for quick pressure visualization
- 25 PSI maximum input pressure rating prevents over-pressurization damage
- Compact receiver-mount design fits standard air tank ports
- U.S. manufactured heritage ensures quality standards compliance
Technical Specifications
Refer to the specifications table below for detailed dimensional and performance data.
Typical Applications
- Compressed air receiver tank monitoring
- Pneumatic tool and equipment pressure verification
- Facility maintenance and preventive inspection
- Service bay air system monitoring
- Manufacturing floor compressed air quality control
- Plumbing and HVAC refrigerant systems (low-pressure applications)
Compatibility & Replacements
Compatible With
- Standard compressed air receivers (25 PSI or lower operating pressure)
- Pneumatic air systems and regulators
- Low-pressure hydraulic circuits (within 25 PSI limit)
- Facility air compressor discharge lines
- Industrial vacuum and pressure switch control circuits
Replaces / Drop-In Replacement For
- Ashcroft Duragauge receiver gauges (equivalent configurations)
- Standard receiver gauges with 25 PSI maximum rating
- Direct replacement for original equipment on air receiver tanks manufactured prior to 2015
Works With
- Mechanical pressure regulators and relief valves
- Manual and automatic drain traps
- Pressure switches and transducers (sensing reference)
- Standard NPT and NPTF male port connections
