Overview
The Sealmaster SFMH-27 is a precision flanged mounted ball bearing engineered for demanding industrial applications. Featuring a 1-11/16″ (1.688″) bore diameter, this unit provides reliable support for rotating shafts in pumps, motors, compressors, and general machinery. Available in new, unopened condition, the SFMH-27 is ready for immediate deployment in your equipment.
Key Features
- Bore Diameter: 1-11/16″ (1.688″) for standard shaft mounting
- Bearing Steel: 52100 Vacuum Degassed Bearing steel for extended service life
- Housing Material: Cast iron for durability and heat dissipation
- Seal Type: Felt labyrinth seal for contamination protection
- Locking Mechanism: Setscrew lock for secure shaft positioning
- Surface Finish: Black oxide coating for corrosion resistance
Technical Specifications
- Bearing Type: Mounted ball bearing
- Bore Size: 1-11/16″ (1.688″)
- Insert Material: 52100 bearing steel
- Housing: Cast iron construction
- Seal: Felt labyrinth seal
- Locking: Setscrew lock
- Operating Temperature Range: -20° to 200°F (standard duty)
- Finish: Black oxide coated
- Relubrication: Yes, grease-lubricated
Typical Applications
- Centrifugal and gear pumps
- Electric motors and turbines
- Industrial compressors and blowers
- Conveyor systems and drives
- HVAC equipment and fans
- General machinery shaft support
Compatibility & Replacements
Compatible With
- Standard industrial machinery requiring 1-11/16″ flanged bearing units
- Equipment designed for four-bolt flange mounting
- Systems requiring grease-lubricated, sealed bearing inserts
- Applications operating at standard duty rating within -20° to 200°F range
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering.
Works With
- Sealmaster standard grease lubricants
- Industrial motor shafts and power transmission equipment
- Standard four-bolt flange mounting blocks
- Shaft sizes commonly paired with 1-11/16″ bearing inserts
