Overview
The Schneider Electric TSXP67455 is a central processing unit for the TSX 47/67/87 Series modular sequential PLCs. This high-performance CPU processor module serves as the central processing unit, managing and executing control instructions for various industrial automation applications. The TSXP67455 combines efficient processing architecture with flexible I/O configuration, making it suitable for material handling, packaging, and production control systems.
Key Features
- Advanced RISC microarchitecture ensures efficient execution of control algorithms
- Operates at 200 MHz, providing swift processing capabilities
- Equipped with 1 MB of flash memory for program storage and data management
- Supports RS-485 and Ethernet interfaces, facilitating seamless integration into industrial networks
- Discrete I/O Type (In-Rack and Remote), 250 kHz Multi-Axis Control Modules, 2-Channel Asynchronous Serial link Modules (RS 232 C, RS 422, RS 485, 20 mA CL)
- Modular design compatible with standard and short-rack configurations (5 to 16 slots)
Technical Specifications
- Processor Clock Speed: 200 MHz
- Memory: 1 MB Flash (Program/Data)
- Internal RAM: 20 Kwords data (expandable to 128 Kwords with PCMCIA card)
- I/O Configuration: Discrete In-Rack and Remote
- Communication Interfaces: RS-232 C, RS-422, RS-485, 20 mA CL
- Networking: FIPIO (1) or FIPWAY
- Processing Speed: Bit Instructions 0.50 ms; Arithmetic Operations 10 ms
- Operating Voltage: Requires a 24V DC power supply
- Operating Temperature Range: -25°C to +70°C
- Dimensions: 5.1 cm × 5.1 cm × 10.2 cm
- Weight: 0.1 to 0.32 kg
- Series: TSX 47/67/87
Typical Applications
The TSXP67455 processor is ideal for:
- Material handling and conveyor systems
- Packaging machinery and production lines
- Textile machine control
- Sequential control processes requiring multi-axis coordination
- Industrial automation with discrete I/O requirements
- Systems requiring remote I/O rack expansion
Compatibility & Replacements
Compatible With
- TSX 47-10, TSX 47-20, TSX 47-25 PLC base modules
- TSX 67 Series controllers
- TSX 87 Series controllers
- Discrete I/O interface modules (all types)
- Remote I/O extension racks (up to 16 slots)
- FIPIO and FIPWAY communication networks
- RS-232, RS-422, RS-485 serial devices
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. The TSXP67455 is part of the legacy TSX Série 7 processor line. Related models include TSXP47400, TSXP47405, TSXP67410, TSXP67420, TSXP87410, and TSXP87420 depending on your specific architecture requirements.
Works With
- Schneider Telemecanique TSX programming platforms
- FIPIO/FIPWAY industrial networks
- Modular I/O coupling modules
- Asynchronous serial communication protocols
- Direct I/O extension racks and short-rack configurations
