Overview
The Rexroth R911295323 HMS01.1N-W0020-A-07-NNNN IndraDrive M is a modular, single-axis servo drive designed for high-performance motion control in industrial automation and manufacturing systems. As part of the IndraDrive M product family, this compact inverter module integrates seamlessly into large axis groups and complex servo applications where space and efficiency are critical. Built on Rexroth engineering standards, the IndraDrive M delivers closed-loop DC bus architecture and mains regeneration capability to maximize energy recovery and system uptime.
Key Features
- 5.5 kW Motor Rating – Supports servo motors up to 5.5 kW for demanding industrial applications.
- Single-Axis Inverter Module – Modular design allows flexible stacking for multi-axis systems without redundant power supplies.
- DC Bus Voltage Input – Accepts 254–750 VDC input with 14 A input current rating.
- 3-Phase AC Output – Delivers 0–500 VAC, 3-phase 0–1000 Hz output for smooth motor control.
- Compact Form Factor – Integrated mains connection components reduce panel size and installation time.
- Mains Regeneration Capability – Enables power recovery during regenerative braking cycles.
Technical Specifications
- Input Voltage Range – 254–750 VDC
- Input Current – 14 A
- Output Voltage – 0–500 VAC, 3-phase
- Output Current – 12.1 A
- Frequency Range – 0–1000 Hz
- Power Rating – 5.5 kW
- Phase Configuration – 3-Phase
- Inverter Type – Digital servo drive
- Weight – 5.45 lbs (2.47 kg)
- Operating Principle – Closed-loop DC bus with integrated mains connection
Typical Applications
- Multi-axis precision machining centers and CNC equipment
- Packaging machinery and automated assembly lines
- Industrial robotics and material handling systems
- Textile and printing machinery servo control
- Press and punch machinery servo positioning
- Test and measurement equipment requiring precise motion
Compatibility & Replacements
Compatible With
- Rexroth IndraDrive M power supply modules (HMV0102, HMP0102, HMP0103)
- Rexroth INDRADRIVE servo motors (single and multi-phase up to 5.5 kW)
- Bosch Rexroth industrial control systems and automation platforms
- AC servo motors rated for 0–500 VAC 3-phase input
- Plant networks requiring 0–1000 Hz variable frequency drive output
Replaces / Drop-In Replacement For
- HMS01.1N-W0020-A-07-NNNN (exact model match)
- Earlier Rexroth single-axis inverter modules in the HMS01 series (verify connector compatibility with system integrator)
Works With
- Rexroth IndraControl and ProfiDrive servo control software
- PROFIBUS and PROFINET industrial networks
- Rexroth DriveControl and iRC motion controllers
- CANopen and EtherCAT fieldbus networks (via compatible masters)
- Standard VFD and servo commissioning tools supporting DC-bus inverters
