Overview
The Numatics 11SAD441C solenoid valve is a pneumatic solenoid-actuated control valve designed for industrial automation, process control, and equipment actuation. With a 120V AC coil and a maximum operating pressure of 150 PSI, it provides direct solenoid control of pneumatic circuits. This model is part of Numatics’ established line of pilot-operated and direct-acting solenoid valves used across manufacturing, bottling, automotive, and metal working facilities.
Key Features
- 120V AC coil voltage (50/60 Hz compatible)
- 150 PSI maximum operating pressure
- Direct solenoid actuation for reliable on-off control
- Industry-standard 1/4″ NPTF port configuration
- Compact, plug-in design for mounting to standard manifolds
- New, open-box condition—fully functional and ready to install
Technical Specifications
- Part Number: 11SAD441C / 237-214B
- Manufacturer: Numatics (ASCO Numatics)
- Coil Voltage: 120V AC, 50/60 Hz
- Maximum Pressure: 150 PSIG
- Operating Temperature: −10°F to +115°F (−23°C to +46°C)
- Port Connection: 1/4″ NPTF
- Spool Configuration: 2-position, 4-way (5/2) solenoid-actuated
- Current Consumption: ~0.12 A holding, 0.4 A inrush at 120V AC
- Condition: New – Open Box
Typical Applications
Numatics solenoid valves like the 11SAD441C are used in:
- Pneumatic actuator control (cylinders, grippers, rotary actuators)
- Automated production machinery and assembly equipment
- Press and stamping room pneumatic circuits
- Bottling, canning, and packaging automation
- Automotive manufacturing and subassembly
- On-off fluid control in test and measurement systems
Compatibility & Replacements
Compatible With
- Numatics Mark 7 series manifold bases and sub-plates
- Standard 1/4″ NPTF pneumatic fittings and hose connections
- Industrial 120V AC single-phase power systems (50/60 Hz)
- Pneumatic control circuits up to 150 PSI
- Direct manifold mounting via plug-in receptacle
Replaces / Drop-In Replacement For
- Numatics 237-214B (alternate part number)
- Legacy Numatics Mark 7 series solenoid coils requiring 120V AC
- ASCO equivalent 120V AC solenoid pilots and actuators
Works With
- Numatics pneumatic logic valves and shuttle logic circuits
- Standard pneumatic cylinders and air-operated devices
- Industrial PLC and motion control systems with 120V AC discrete output
- Proportional and directional control manifolds with dual solenoid architecture
