Overview
The Newport Q2000-E 4-20mA panel meter is a professional-grade digital process signal receiver built on the proven Quanta platform. This 3-1/2-digit unit accepts standard 4-20mA analog inputs and displays them in user-configurable engineering units. The compact 1/8 DIN form factor fits standard industrial panel cutouts, making it ideal for retrofit and new installations in process control, HVAC monitoring, and equipment telemetry applications.
Key Features
- 3-1/2-digit LCD display for clear signal visibility
- 4-20mA input configuration with broad signal conditioning range
- Extensive zero and span adjustment via accessible potentiometers
- Plug-in jumper selection for input range scaling
- On-board shunts and attenuators for signal matching
- 1/8 DIN panel-mount form factor
Technical Specifications
- Display Type: 3-1/2 digit LCD
- Input Signal: 4-20mA (configurable via jumpers)
- Display Range: -1999 to +1999 counts
- Digit Height: 14.2 mm
- Panel Cutout Height: 44.96 mm
- Case Material: Polycarbonate
- Mounting Style: Panel-mount with slide retainers
- Adjustment: Fine-zero and fine-span potentiometers (behind lens)
Typical Applications
- Process flow rate and pressure monitoring
- HVAC system diagnostics and control readout
- Industrial equipment load and status display
- Analog transmitter signal verification
- Machine and facility automation panels
Compatibility & Replacements
Compatible With
- 4-20mA current loop transmitters and sensors
- Standard industrial control panels with 1/8 DIN cutouts
- Field-calibration potentiometers and shunt networks
- Plug-in signal conditioner modules (Q2000 series)
Replaces / Drop-In Replacement For
- Newport Q2000-P variant (with LCD display option)
- Other Newport Quanta Q2000 current input models
- Legacy analog panel meters in 4-20mA applications
Works With
- 4-20mA analog control loops and process networks
- Standard industrial transmitters (pressure, flow, temperature)
- Manual field calibration and zero/span adjustment
- No software or network interface required
