Overview
The KENDRION GT-50-A-1 electromagnet is a compact AC-powered magnet designed for reliable holding and clamping of ferromagnetic workpieces in industrial applications. Operating at 24V AC with a 5W power rating, this unit combines efficient power consumption with proven electromagnetic performance. KENDRION electromagnets are engineered to meet stringent industrial reliability standards and are widely deployed in automation, material handling, and machine tool industries.
Key Features
- 24V AC operation at 5W power consumption
- 50mm diameter compact round design
- KENDRION-engineered electromagnet with proven industrial reliability
- Suitable for holding, clamping, and positioning of ferromagnetic materials
- Standard mounting compatible with KENDRION fixture systems
- Low-current, maintenance-free operation
Technical Specifications
- Model: GT-50-A-1
- Manufacturer: KENDRION
- Supply Voltage: 24V AC
- Power Rating: 5W
- Body Diameter: 50mm
- Coil: Resin vacuum-potted for dust, oil, and moisture protection
- Operating Temperature Range: 0°C to +60°C (standard)
- Environmental Protection: Potted coil design
- Connection Type: Flying lead (standard)
Typical Applications
KENDRION electromagnets are widely used in:
- Fixture construction and workpiece clamping
- Material handling and lifting systems (with appropriate safety factors)
- Automation and robotic pick-and-place systems
- Machine tool guards and safety interlocks
- Transporting and positioning ferromagnetic components
- Industrial conveyor and sorting systems
Compatibility & Replacements
Compatible With
- KENDRION standard mounting brackets and anchor plates
- 24V AC power supplies (50/60 Hz)
- Industrial control systems requiring electromagnet actuation
- Fixture construction frameworks
- Standard ferromagnetic armature plates and pole pieces
Replaces / Drop-In Replacement For
Direct replacement information for the GT-50-A-1 is limited in available technical documentation. Verify compatibility with your system integrator or contact KENDRION technical support before ordering to ensure proper fit and performance in your application.
Works With
- 24V AC control relays and contactors
- Industrial PLC outputs (with appropriate relay/contactor interface)
- Machine automation control circuits
- Standard electromagnetic holding and release circuits
