Overview
The Lenze MCS 06F41LRS0B0-B11N-ST5S00N-R2SU is a compact synchronous servo motor engineered for demanding industrial automation and motion control applications. Manufactured by Lenze, a leading German automation supplier, this servo motor combines reliable AC synchronous drive technology with resolver feedback for closed-loop control. The 06F frame size and 0.51 kW power rating make it ideal for applications requiring precise speed and torque regulation.
Key Features
- Synchronous servo design—precise, repeatable motion with no slip between load and motor
- Resolver feedback—continuous position and speed feedback for accurate control loops
- 400 VAC three-phase—standard industrial power supply compatibility
- IP54 protection rating—sealed against dust and moisture splashes for factory environments
- 11 mm shaft diameter—compatible with standard couplings and gearbox adapters
- No integrated brake—focus on continuous motion control without holding function
Technical Specifications
- Power Output: 0.51 kW (0.68 HP)
- Input Voltage: 400 VAC three-phase, 50/60 Hz
- Rated Current: 1.5 A
- Speed (Synchronous): 4050 RPM
- Torque: 1.20 Nm continuous
- Motor Frame: 06F (MCS series)
- Feedback Type: Resolver
- Shaft Diameter: 11 mm
- Shaft Type: Standard with key (for LRS variant)
- Protection Class: IP54
- Cooling: Natural ventilation
- Weight: Approximately 5.4 lbs
- Connector Type: Round plugs
- Brake: None
Typical Applications
- Packaging and labeling machinery
- Textile looms and weaving equipment
- Print finishing systems
- Conveyor belt drives with speed regulation
- Spindle drives for light machining
- Machine tool positioning tables
- Automated assembly systems requiring synchronized motion
Compatibility & Replacements
Compatible With
- Lenze inverter drives and AC servo drives supporting 400 VAC input
- Industrial control systems with resolver feedback support
- Standard flexible couplings (11 mm bore)
- Parallel-key shaft mounting (keyed variant)
Replaces / Drop-In Replacement For
- MCS06F41-RS0B0-B11N-ST5S00N (earlier variant without resolver)
- Verify exact model compatibility with your OEM or drive manufacturer before ordering
Works With
- Lenze FREQUROLLING and INVERTEK servo drive systems
- Siemens S7-1200/1500 PLC with resolver analog input modules
- Allen-Bradley CompactLogix systems with appropriate resolver/feedback modules
- EtherCAT and Profinet networks via compatible motion control modules
- Industrial automation software supporting 400 VAC AC servo control
